OPERATION 800D
2-8
Published 5-27-2018 Control # 039-06
1. Upon startup, allow the engine to idle for 3 to 5 minutes
before operating with a load.
2. Cold Engine Startup: After allowing the engine to warm
by idling it for 3 to 5 minutes, slowly increase the engine
speed to provide adequate lubrication to the bearings
and to allow the oil pressure to stabilize.
Transmission
NOTE: For National Crane transmission warm-up
procedures, refer to chassis manufacturer’s
manual.
Operating the transmission with a sump temperature below
normal operating temperature is limited to:
• operating in the neutral gear or
• driving with an unloaded crane while not exceeding
1500 engine RPM and not exceeding half throttle.
Alternate Warm-up Procedures for Truck Mount (TM/TMS)
Cranes:
1. Setup the crane on outriggers.
2. Engage the transmission and allow crane to run at idle
until the temperature of the transmission sump reaches
normal operating temperature.
Hoist
Performing a warm-up procedure is recommended at every
startup and is required at ambient temperatures below 4°C
(40°F).
Warm-up Procedures:
1. Without operating the hoist function, warm the hydraulic
oil (see Hydraulic Oil System, page 2-8).
2. After the hydraulic system is warm, operate the
unloaded hoist, in both directions, at low speeds several
times to prime all hydraulic lines with warm hydraulic oil
and to circulate gear lubricant through the planetary
gear sets.
Swing Drive and Turntable Bearing
Warm-up Procedures for Temperatures Above -7°C (20°F):
1. Setup the crane on fully extended outriggers, with the
boom fully retracted and near maximum lift angle with no
load applied.
2. Rotate the superstructure at a speed of less than one
RPM for at least one complete revolution in one
direction, then rotate the superstructure at a speed of
less than one RPM for at least one complete revolution
in the opposite direction.
Warm-up Procedures for Temperatures Below -7°C (20°F):
1. Ensure the boom is fully retracted and near maximum lift
angle with no load applied.
2. Rotate the superstructure at a speed of less than one-
half RPM for at least two complete revolutions in one
direction, then rotate the superstructure at a speed of
less than one-half RPM for at least two complete
revolutions in the opposite direction.
Axles
NOTE: For National Crane axle warm-up procedures, refer
to chassis manufacturer’s manual.
Hydraulic Oil System
Operating Limits and Warm-up Procedures:
• From 4°C to -10°C (40°F to 15°F): Crane operation
without
a load is allowed with medium engine RPM and
medium function speed (joystick position) until the fluid
reaches at least 10°C (50°F). It is then recommended
that all crane functions be cycled to remove cold fluid
from all components and cylinders of the hydraulic
system. If there is any unusual sound coming from the
crane’s hydraulic pumps or motors, stop the operation
and engine immediately and contact a National Crane
distributor.
• From 10°C to 4°C (50°F to 40°F): Crane operation with
a load is allowed with medium engine RPM and medium
function speed (joystick position) until the fluid reaches
at least 10°C (50°F).
• From 95°C to 10°C (200°F to 50°F): Crane operation
with a load is allowed with no restrictions.
• Above 95°C (200°F): No crane operation is allowed. Let
the crane’s hydraulic oil cool by running the engine at
idle with no functions actuated.
Pre-Operation Inspection and Calibration
Verification
1. Check the electrical wiring connecting the various parts
of the system for physical damage.
2. Check the anti-two-block switches and weights for free
movement.
The following tests shall be performed with care to
prevent damage to the machine or injury to personnel.
Proper functioning of the system requires successful
completion of these tests before operating the machine.
