WIDE BASE RADIAL TIRES FOR TRUCKS IN NORMAL HIGHWAY SERVICE
(TIRES USED AS SINGLES)
TIRE SIZE
DESIGNATION
TIRE LOAD LIMITS, LB (kg), AT VARIOUS COLD INFLATION PRESSURES, PSI (kPa)
70
(483)
75
(517)
80
(552)
85
(586)
90
(621)
95
(655)
100
(690)
105
(724)
110
(758)
115
(793)
120
(827)
445/65R19.5 7540
(3420)
7930
(3597)
8270
(3751)
8680
(3937)
9040
(4101)
9370
(4250)
9730
(4413)
10,100
(4581)
10,500 (J)
(4763) (J)
385/65R22.5 6380
(2894)
6710
(3044)
7040
(3193)
7350
(3334)
7650
(3470)
7950
(3606)
8230
(3733)
8510
(3860)
8790
(3987)
9050
(4105)
9370 (J)
(4250) (J)
425/65R22.5 7590
(3443)
7990
(3624)
8370
(3797)
8740
(3964)
9100
(4128)
9450
(4286)
9790
(4441)
10,100
(4581)
10,500
(4763)
445/65R22.5 8280
(3756)
8710
(3951)
9120
(4137)
9540
(4327)
9930
(4504)
10,300
(4672)
10,700
(4853)
11,000
(4990)
11,400 (J)
(5171) (J)
11,700
(5307)
12,300 (J)
(5579) (J)
NOTE: Letters in parentheses denote Load Range for which Bold Face Loads are maximum.
TIRES FOR TRUCKS IN NORMAL HIGHWAY SERVICE
(TIRES MOUNTED ON FLAT BASE RIMS)
TIRE SIZE
DESIGNATION
USAGE
TIRE LOAD LIMITS, LB (kg), AT VARIOUS COLD INFLATION PRESSURES, PSI (kPa)
RADIAL PLY
70
(483)
75
(517)
80
(552)
85
(586)
90
(621)
95
(655)
100
(690)
105
(724)
110
(758)
115
(793)
120
(827)
10.00*20 DUAL
SINGLE
4380
(1987)
4530
(2055)
4580
(2077)
4770
(2164)
4760(F)
(2159) (F)
4990
(2263)
4950
(2245)
5220
(2368)
5120
(2322)
5430(F)
(2463) (F)
5300(G)
(2404) (G)
5640
(2558)
5470
(2481)
5840
(2649)
5630
(2554)
6040 (G)
(2740) (G)
5800 (H)
(2631) (H)
6240
(2830)
6430
(2917)
6610(H)
(2998) (H)
10.00*22 DUAL
SINGLE
4660
(2114)
4820
(2186)
4870
(2209)
5070
(2300)
5070(F)
(2300) (F)
5310
(2409)
5260
(2386)
5550
(2517)
5450
(2472)
5780(F)
(2622) (F)
5640(G)
(2558) (G)
6000
(2722)
5820
(2640)
6210
(2817)
6000
(2722)
6430(G)
(2917) (G)
6170(H)
(2799) (H)
6630
(3007)
6840
(3103)
7030 (H)
(3189) (H)
11.00*20 DUAL
SINGLE
4780
(2168)
4940
(2241)
4990
(2263)
5200
(2359)
5190(F)
(2354) (F)
5450
(2472)
5390
(2445)
5690
(2581)
5590
(2536)
5920(F)
(2685) (F)
5780(G)
(2622) (G)
6140
(2785)
5960
(2703)
6370
(2889)
6150
(2790)
6590(G)
(2989) (G)
6320(H)
(2867) (H)
6790
(3080)
7010
(3180)
7200(H)
(3266) (H)
11.00*22 DUAL
SINGLE
5080
(2304)
5240
(2377)
5300
(2404)
5520
(2504)
5520(F)
(2504) (F)
5790
(2626)
5730
(2599)
6040
(2740)
5940
(2694)
6290(F)
(2853) (F)
6140 (G)
(2785) (G)
6530
(2962)
6330
(2871)
6770
(3071)
6530
(2962)
7000 (G)
(3175) (G)
6720 (H)
(3048) (H)
7220
(3275)
7440
(3375)
7660(H)
(3475) (H)
11.00*24 DUAL
SINGLE
5390
(2445)
5570
(2527)
5630
(2554)
5860
(2658)
5860(F)
(2658) (F)
6140
(2785)
6090
(2762)
6420
(2912)
6310
(2862)
6680(F)
(3030) (F)
6520(G)
(2957) (G)
6940
(3148)
6730
(3053)
7190
(3261)
6930
(3143)
7430(G)
(3370) (G)
7130 (H)
(3234) (H)
7670
(3479)
7900
(3583)
8130 (H)
(3688) (H)
12.00*20 DUAL
SINGLE
5440
(2468)
5620
(2549)
5680
(2576)
5920
(2685)
5910
(2681)
6200
(2812)
6140(G)
(2785) (G)
6480
(2939)
6360
(2885)
6740
(3057)
6580
(2985)
7000(G)
(3175) (G)
6790(H)
(3080) (H)
7250
(3289)
7000
(3175)
7500
(3402)
7200 (J)
(3266) (J)
7740(H)
(3511) (H)
7980
(3620)
8210 (J)
(3724) (J)
12.00*24 DUAL
SINGLE
6120
(2776)
6330
(2871)
6390
(2898)
6660
(3021)
6650
(3016)
6980
(3166)
6910(G)
(3134) (G)
7280
(3302)
7160
(3248)
7580
(3438)
7410
(3361)
7880(G)
(3574) (G)
7640 (H)
(3465) (H)
8160
(3701)
7870
(3570)
8450
(3833)
8100 (J)
(3674) (J)
8710 (H)
(3951) (H)
8970
(4069)
9230 (J)
(4187) (J)
* Tire size designation will include “R” (Radial Ply)
NOTE: Letters in parentheses denote Load Range for which Bold Face Loads are maximum
