10
D00619EN - v0 SWING OPERATOR - INSTALLATION MANUAL
4 PRE-INSTALLATION
4.1 Training Requirements for Installation Technicians
Installing machines as well as any other intervention for maintenance, regulation adjustment, etc should be carried
out by qualified technical staff that meet the following requirements:
• Know how to use the maintenance and/or lifting equipment.
• Are able to correctly handle the loads.
• Know how to use the personal protective equipment.
• Know how to apply the Low Voltage Regulations instructions.
• Have technical knowledge of products.
• Know the reference and application standards for products and services.
4.2 Physical and Environmental Requirements
The VECTOR swing operator should be installed in places that meet the following requirements:
• Smooth, flat, level floor.
• Smooth, flat, level wall with sufficient load capacity. Capable of anchoring a suitable frame.
• An area free from shocks and vibrations.
Ambient temperature: -15 a +50ºC.
• Do not expose to direct sunlight.
• Do not expose to rain or excessive humidity.
Consideration of the location for the equipment should be carried out by technical personnel authorised by
During this process, the cable inlet location for the for the different units should be identified.
PRESSURE
In installations where the swing door is to be installed between two rooms with different pressure, it is recommended
that the door is planned for and installed such that the positive pressure always acts in the direction that the leaf
closes, thus helping to maintain the closed position.
