5.12 Arm-Type Selection
Rigid arm (Left or right-opening leaf)
→ Configure the right program switch as shown in Fig. 11.
Articulated arm (Left and right-opening leaf)
→ Configure the left program switch as shown in Fig. 11.
5.13 Connecting the Controls/Inputs
SIGNAL DEFAULT
*
DESCRIPTION FUNCTION
KEY NC
Lock signal. Closing
devices, such as the
electronic key, the
key program switch,
the transponder, etc.,
may be connected.
If the signal starts, the central unit controls the full leaf closing (from any
position). Until this signal is no longer received, the door will remain
closed and will not detect any external peripheral devices (including the
multi-logic program switches).
The signal should be shorted with COM if there are no devices connected.
START 1 NO
Opening signal. De-
vices can be connect-
ed for leaf opening
control.
The end of this signal causes the leaves to open. This signal is controlled
only with 2 radars logic setting.
START 2 NO
Opening signal. De-
vices can be connect-
ed for leaf opening
control.
The end of this signal causes the leaves to open. This signal is controlled
both with 2 radars logic setting and 1 radar logic setting.
SAFE
OPEN
NC
Opening safety sig-
nal: other protective
sensors can be con-
nected for additional
safety during the
opening phases of
the leaves.
If the door is in the opening phase and the contact is open, the central unit
will order the manoeuvre to immediately stop. Opening will continue only
after this signal has been deactivated.
The signal should be shorted with COM if there are no devices connected.
SAFE
CLOSE
NC
Closing safety signal:
other protective sen-
sors can be connect-
ed for additional safe-
ty during the closing
phases of the leaf.
If the door is in the closing phase and the contact is open, the central unit
will immediately order the reverse movement. Closing will start again only
once the contact is closed again.
The signal should be shorted with COM if there are no devices (internal or
external) connected.
COM Common in electrical signals.
AUX IN 1
AUX IN 2
NO
Signal that, depending on the settings, may have the following configurations:
0 - Disabled persons
opening
Opening control for disabled persons. LOW ENERGY open and close with
a minimum 5 second pause.
1 - Emergency
opening
It controls door opening regardless of the existing logic settings, overriding
as priority even the KEY input.
2 - Door interlocking
with priority
It identifies the device used in the interlocking logic setting, with the door’s
as priority.
3 - Door interlocking
without priority
It identifies the device used in the interlocking logic setting, with the door’s
without priority
4 - Lock release
feedback
Control used to indicate that the lock is released. Connect the micro-
switch or the contact to detect the state of the released lock.
5 - Lock release
control
Control allowing the lock to be released manually, without controlling the
opening of the leaf.
6 - Individual control
with Double operation
mode
Signal that allows the device to be controlled as if it were individual when
it operates with a double leaf.
