D00619EN - v0 SWING OPERATOR - INSTALLATION MANUAL
7.5 Safety Regulations
The safety-improvement measures implemented during the design of the unit are:
• Easy operation.
• Limited number of tools and equipment.
• Easy monitoring.
• Accessibility to internal parts.
• The operators are protected by a metal chassis avoiding unauthorised unauthorized or malicious manipulation
• There are no loose pieces or fastenings coming from the chassis opening.
• Once the chassis is open, the cable to connect to the power supply is easily accessible.
8 MAINTENANCE AND INSPECTION
8.1 General Maintenance to Be Performed by the User
The user’s maintenance duties are limited, exclusively, to keeping the door area clean and tidy.
All maintenance operations, apart from functional tests, must be carried out after disconnecting the power from the
mains.
If the mains cable is damaged, it needs to be replaced by a special set or cable, supplied by the manufacturer or by
your after-sales services.
Installation, maintenance, adjustment and repair tasks should only be carried out by technical staff authorised by .
CARACTERÍSTICAS MECÁNICAS.
8.2 Maintenance Tasks Exclusively Reserved for the Manufacturer
If the program manager detects anomalies in the door operation, the operator includes various protective measures to prevent
major system damage.
The different system errors are shown in 7 segment displays to signal operating conditions:
In the majority of cases, to resume door operation it will be enough to select the door open mode and then
the automatic door mode. If after this operation the anomaly persists, it will be necessary to resort to a
manusa authorised service technician.
9 TROUBLESHOOTING
SIGNAL DESCRIPTION
OP on Door open
OP Flashing Door opening
CL on Door closed
CL Flashing Door closing
E1 Error derived from not initiating the system parameters (self-learning)
E2
Device type (Dip 5), or arm type (Dip 1 or configuration of the arm in the passive brake card)
selection error
E3/E4 Maximum current threshold exceeded error (OVER CURRENT)
E6 Supervised sensors error
E8 Coder connection error
Only original spare parts must be used.
