D00619EN - v0 SWING OPERATOR - INSTALLATION MANUAL
The symbols that appear in this manual and/or in the machine are listed below:
1.2 Symbol Description
ELECTRICAL HAZARD. The inside of the machine must
not be manipulated unless it has been previously
disconnected from the power supply.
DANGER. Improper use may cause injuries to people
and damage the machine.
IMPORTANT WARNING. Strictly adhere to the
indicaons provided with this symbol.
OPTIONAL. These elements are oponal; they will be
included in the box depending on the order placed.
LEFT
Side Opening
BI-PARTING RIGHT
Side Opening
):
1.3 Versions
Both the operator and the two arm versions (dragging and pushing) are universal for any leaf typology: bi-parting, left
and right opening.
It is available in the following transmission arm configurations, in single or bi-parting variants:
Drag arm: attached to the wall on the same side as the hinges (see picture).
Push arm: attached to the wall on the opposite side as the hinges (see picture).
