D00619EN - v0 SWING OPERATOR - INSTALLATION MANUAL
This manual details all the basic instructions for assembling the automatic door. Read it thoroughly and, when in doubt,
contact the Technical Support Department (see back of the manual).
For your own safety, adhere at all times to all the technical instructions detailed in this manual. manusa accepts no
responsibility for damages and faults derived from not complying with these instructions.
Finally, we would like to thank you for your trust in acquiring a product from the manusa range, a company with more than
50 years experience designing, manufacturing and installing automatic access systems.
Drag arm
B
1.1
VECTOR Swing Operator
A
1.1
Push arm
C
1.1
17. Drag arm
18. Drag guide profile
19. Arm-to-leaf anchor
20. Joints
21. Adjustable-depth plate
22. Push arm
17 18
19
21 22
20
2
3
1
4 5
6
7
8
9
10
11
13
14 12
15
16
1. Blind side cover
2. Cover screws
3. Main chassis profile
4. Re-send mechanism
5. Axis with upper and lower outputs
6. Gear
7. Motor
8. Electronics
9. Navigation buttons
10. Operator control display
11. Transformer
12. Installation screws
13. Filter
14. Side cover
15. Mode selection program switch/ Mode switch
16. ON-OFF button
