Sound modes and channel output
S This indicates the audio output channels or surround parameters that can be set.
D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.” (vpage145).
Sound mode (vpage94)
Channel output
Front L/R Center Surround L/R Subwoofer
DIRECT/PURE DIRECT (2-channel)
S Dz
DIRECT/PURE DIRECT (Multi-channel)
S D D D
STEREO
S D
MULTI CH IN
S D D D
DOLBY PRO LOGIC g S D D D
DTS NEO:6
S D D D
DOLBY DIGITAL
S D D D
DOLBY DIGITAL Plus
S D D D
DOLBY TrueHD
S D D D
DTS SURROUND
S D D D
DTS 96/24
S D D D
DTS-HD
S D D D
DTS Express
S D D D
MULTI CH STEREO
S D D D
VIRTUAL
S D
z Audio is output when “Subwoofer Mode” (vpage148) in the menu is set to “LFE+Main”.
