1. SERVICE MODE
1. To enter the Service Mode, press the ON/OFF button with pressing the DISPLAY and ATT buttons to turn on the unit.
Or when the remote code "166363" is
received while power is ON.
When into the Service Mode, the memory is cleared and the unit is initialized.
2. The Model name and Version number are displayed on the Front LCD.
Whenever press the DISPLAY button, the display changes as follows.
Turn off power to quit service mode.
Displays the number of protection detected
Initial settings
ID No. : 0
SIDE ILLUMINATION : ON
LEVEL TRIM : 0.0(L/R)
BASS TRIM : 0
TREBLE TRIM : 0
ATT : -20 dB
ATT : OFF
VOLUME : -∞
INPUT SELECTOR : CD
DISPLAY : ON
TONE : OFF
PHONO MC : OFF (MM)
PRE OUT : OFF
POWER AMP DIRECT : OFF
SPEAKER A : OFF
SPEAKER B : OFF
POWER ON/STANDBY : ON
AUTO STANDBY MODE :
ON
Be sure to set up manually.
MODE SW on Rear panel : STEREO,
X
ON/OFF SW : OFF
2. SERIAL NUMBER CHECK MODE
1. To enter the serial number check mode, press the
X
ON/OFF button with pressing the TONE and PHONO MC buttons
to turn on the unit.
2. The Serial number is displayed on the Front LCD.
Turn off power to quit serial number check mode.
16th 17th 18th
20th 21th 22th
24th 25th 26th
19th
23th
Press
Press
Press
Press
Press
Press
Press Press
PressPress
V120425
PM11S3
BUS OK
BUS TEST
BUS NG
BUS TEST
0 0
1-PROT-2
- o o
CD
All LCD's are disappear
OK is displayed when there is no problem with the communication
Displays the number of
protection detected
Connect connector
IN and Out of F.C.B.S
NG is displayed when there is problem with the communication
Blinks alternately
Press
Press
PressPressPress
After 3
seconds
To Next Page
