Marantz PM-11S3 Service Manual

80
HDAM-SA3D ASS'Y
Ref No. Part No. Part Name Remark Q'ty New
DN01 00MHZ20014990 KDS122 TAPING
DN02 00MHZ20014990 KDS122 TAPING
DN03 00MHZ20014990 KDS122 TAPING
DN04 00MHZ20014990 KDS122 TAPING
JN01 00MYP07005670 IMSA-6065B-06Z065-PT1
QN01 00D2710318909 2N5401S-RTK/P
QN02 00D2730479909 2N5551S-RTK/P
QN03 00D2710318909 2N5401S-RTK/P
QN04 00D2730479909 2N5551S-RTK/P
QN05 00D2730479909 2N5551S-RTK/P
QN06 00D2710318909 2N5401S-RTK/P
QN07 00D2730479909 2N5551S-RTK/P
QN08 00D2710318909 2N5401S-RTK/P
RN01 nsp 10 OHM +-1% 1/4W
RN02 nsp 10 OHM +-1% 1/4W
RN05 nsp 10 OHM +-1% 1/4W
RN06 nsp 10 OHM +-1% 1/4W

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
