Marantz PM-11S3 Service Manual

41
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
PCB ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the PCB ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model G : Silver gold model
Ref No. Part No. Part Name Remarks Q'ty New
P101 nsp PRE AMP PWB ASSY
P401 nsp PHONO/BALANCE PWB ASSY
P601 nsp L CH POWER AMP PWB ASSY
P651 nsp L CH POSISTOR PWB ASSY
P701 nsp R CH POWER AMP PWB ASSY
P751 nsp R CH POSISTOR PWB ASSY
P801 nsp POWER SUPPLY PWB ASSY
P851 nsp SOFT START PWB ASSY
P871 nsp GND TO CHASSIS PWB ASSY
P891 nsp POWER SWITCH PWB ASSY
P901 nsp SPEAKER OUT PWB ASSY
P991 nsp HEAD PHONE PWB ASSY
PA01 nsp PRE/P-DIRECT/REC PWB ASSY
PB01 nsp BUS INTERFACE PWB ASSY
PC01 nsp BALANCE INPUT PWB ASSY
PD01 nsp U-COM PWB ASSY
PD21 nsp TACT SWITCH LEFT PWB ASSY
PD31 nsp TACT SWITCH RIGHT PWB ASSY
PD41 nsp BACK LIGHT PWB ASSY
PD61 nsp SELECTOR PWB ASSY
PD71 nsp VOLUME PWB ASSY
PG01 nsp REGULATOR PWB ASSY
001B 00M04AJ248120 FRONT PANEL GL PM-11S3 A363 N1G, FN, K1G 1 *
001B 00M04AJ248020 FRONT PANEL BL PM-11S3 A363 N1B, U1B 1 *
001D 40341005901AM TOP COVER GL PM-11S3 A363 N1G, FN, K1G 1 *
001D 40341005900AM TOP COVER BL PM-11S3 A363 N1B, U1B 1 *
001G nsp MAIN CHASSIS 1
001K nsp O63.5 RETAINER (CU) BLSC-641 1
001L nsp MAIN HEATSINK 2
002B 00M04AJ353150 RING WINDOW PM-11S3 GL N A363 N1G 1 *
002B 00M04AJ353020 RING WINDOW PM-11S3 BL A363 N1B, U1B 1 *
002B 00M04AJ353120 WINDOW RING (GL) FN, K1G 1
002D nsp RETAINER TOPCOVER FRONT 1
002G nsp BOTTOM LID 1
002K nsp SPACER CONDENSER PM-11S3 1 *
002L nsp MAIN HEATSINK BRACKET 4
003B 00M04AJ158010 WINDOW 1
004B 00M04AJ353130 POWER BUTTON RING (GL) N1G, FN, K1G 1
004B 00M04AJ353030 POWER BUTTON RING BLACK N1B, U1B 1
004D nsp RETAINER TOPCOVER SIDE 2
004G 00M04AJ057512 LEGS(GOLD) N1G, FN, K1G 4
004G 00M04AJ057522 LEGS(SILVER) N1B, U1B 4
004L nsp STUD M3 9mm 8

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
