Marantz PM-11S3 Service Manual

56
PARTS LIST OF PCB UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
8U-210121A PCB ASS'Y (N1G, K1G model) /
8U-210121B PCB ASS'Y (N1B model) /
8U-210121C PCB ASS'Y (FN model) /
8U-210121D PCB ASS'Y (U1B model)
8U-210121 ASS'Y
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
Q2001 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2002 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2003 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2004 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2005 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2006 00D2690192902 KRC102S-RTK/P (10K-10K)
Q2007 00D2690184907 KRA102S-RTK/P (10K-10K)
Q2008 00D2730460905 KTC2875-B-RTK/P
Q2009 00D2730460905 KTC2875-B-RTK/P
Q2010 00D2730460905 KTC2875-B-RTK/P
Q2011 00D2730460905 KTC2875-B-RTK/P
Q3501 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3502 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3503 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3504 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3505 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3506 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3507 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3508 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3509 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3601 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3602 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3801 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3802 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3901 00D2690192902 KRC102S-RTK/P (10K-10K)
Q3902 21305001240AS KTC3198-GR-AT/P
Q4001 00MHX113121B0 2SA1312 (B)
Q4002 00MHX113121B0 2SA1312 (B)
Q4003 00MHX333241B0 2SC3324 (B)
Q4004 00MHX333241B0 2SC3324 (B)
Q4005 00MHX333241B0 2SC3324 (B)
Q4006 00MHX333241B0 2SC3324 (B)
Q4007 00MHX113121B0 2SA1312 (B)
Q4008 00MHX113121B0 2SA1312 (B)
Q4009 00MHX333241B0 2SC3324 (B)
Q4010 00MHX333241B0 2SC3324 (B)
Q4011 00MHX113121B0 2SA1312 (B)
Q4012 00MHX113121B0 2SA1312 (B)
Q4013 00MHX113121B0 2SA1312 (B)
