Marantz PM-11S3 Service Manual

46
PARTS LIST OF PACKING & ACCESSORIES
z
Parts indicated by "nsp" on this table cannot be supplied.
z
Parts indicated by the "
★
" mark are not illustrated in the packing view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE: The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model G : Silver gold model
Ref No. Part No. Part Name Remarks Q'ty New
1 53121022100AM PACKING CASE PM-11S3 A363 U1B,N1B,N1G,FN 1 *
1 53121022110AM PACKING CASE PM-11S3 A363 K1G 1 *
2 53121022200AM MASTER CARTON PM-11S3 A363 N1B,N1G 1 *
3 00M04AJ809022 CUSHION (R) 1 *
4 00M04AJ809012 CUSHION (L) 1 *
5 nsp SHEET (AF+PE) 1
6 nsp REINFORCE PM-11S2 04AJ 4 *
7 - ENVELOPE SUB ASASY (N inst) N1B, N1G 1
7-1 nsp POLYETHY BAG N1B, N1G 1
7-2 54111089400AM INST.MANUAL PM-11S3 (N) N1B, N1G 1 *
7-3 30701011600AM RC001PMSA 1 *
7-4 nsp BATTERY(R03X2) 2
7 - ENVELOPE SUB ASASY (U inst) U1B 1
7-1 nsp POLYETHY BAG 1
7-2 nsp INST.MANUAL PM-11S3 (U) U1B 1 *
7-3 nsp WARRANTY CANADA U1B 1
7-4 54311010512AM WARRANTY USA U1B 1
7-5 30701011600AM RC001PMSA 1 *
7-6 00D3940030001 BATTERY(R03X2) 2
7 - ENVELOPE SUB ASASY (K inst) K1G 1
7-1 nsp POLYETHY BAG 1
7-2 54111089800AM INST.MANUAL PM-11S3 (K) K1G 1 *
7-3 30701011600AM RC001PMSA 1 *
7-4 nsp BATTERY(R03X2) 2
7 - ENVELOPE SUB ASASY (F inst) FN 1
7-1 nsp POLYETHY BAG 1
7-2 nsp INST.MANUAL PM-11S3 (F) FN 1 *
7-3 nsp USER CARD (F) FN 1
7-4 00M416K851233 SHEET SERVICE ADRESS (F) FN
7-5 30701011600AM RC001PMSA 1 *
7-6 nsp BATTERY(R03X2) 2
8 - ENVELOPE SUB ASSY (AC CORD) N1B,N1G 1
8-1 nsp POLY COVER U1B,N1B,N1G,K1G 1
z
8-2 00MZC01803080 # 2P AC CORD 10A 250V CLASS2 N1B,N1G 1
8 - ENVELOPE SUB ASSY (AC CORD) U1B 1
8-1 nsp POLY COVER U1B,N1B,N1G,K1G 1
z
8-2 00MZC01803100 # AC CORD UL/CSA 10A 125V U1B 1
8 - ENVELOPE SUB ASSY (AC CORD) K1G 1
8-1 nsp POLY COVER U1B,N1B,N1G,K1G 1
z
8-2 00D2062249001 AC CORD (E1C) K1G 1
z
8 61105004200AS OFC AC CORD SET(H20) FN 1
9 nsp WARRANTY FOR CHINA MARANTZ K1G 1
9 nsp WARRANTY F (HOSHOUSHO) FN 1
10 nsp CONTROL LABEL SUB ASSY PM11S3 (N1G) N1B 1 *
10 nsp CONTROL LABEL SUB ASSY PM11S3 (N1G) N1G 2 *
10 nsp CONTROL LABEL SUB ASSY PM11S3 (U1B) U1B 1 *
10 nsp CONTROL LABEL SUB ASSY PM11S3 (K1G) K1G 1 *
10 nsp CONTROL LABEL SUB ASSY PM11S3 (FN) FN 1 *

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
