Marantz PM-11S3 Service Manual

17
1.THE POWER CAN NOT BE TURNED ON
(STANDBY LED DOES NOT LIGHT (STANDBY MODE))
Check linsertion of the 8U-110131-4
STANDBY PWB UNIT.
Check linsertion of the 8U-210120-1
STANDBY PWB UNIT.
Broken wire in SUB
TRANS T8501.
Malfunction of
D8501-8507.
Malfunction of
D8501, U1001.
Check whether power is being
supplied to the coil of the SUB
TRANS T8501.
Check whether power
is being supplied to
the D8501-8507.
Power not supplied.
Power not supplied.
Power supplied.
Power supplied.

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
