Marantz PM-11S3 Service Manual

67
8U-110131 ASS'Y
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
D6001 20105001130AS 1SS133(HOMI)
D6002 20105001130AS 1SS133(HOMI)
D6003 20105001130AS 1SS133(HOMI)
D6004 20105001130AS 1SS133(HOMI)
D6007 00MHI10115210 SLR-342VRTB7 RED TAPING
D6008 00MHI10115210 SLR-342VRTB7 RED TAPING
D6009 20105001130AS 1SS133(HOMI)
D6010 20105001130AS 1SS133(HOMI)
D6011 20105001130AS 1SS133(HOMI)
D6012 20105001130AS 1SS133(HOMI)
D6013 20105001130AS 1SS133(HOMI)
D6014 20105001130AS 1SS133(HOMI)
D6017 20105001130AS 1SS133(HOMI)
D6018 20105001130AS 1SS133(HOMI)
D6019 20105001130AS 1SS133(HOMI)
D6020 20105001130AS 1SS133(HOMI)
D6021 20105001130AS 1SS133(HOMI)
D6022 20105001130AS 1SS133(HOMI)
D6023 20105001130AS 1SS133(HOMI)
D6024 20105001130AS 1SS133(HOMI)
D6025 00D2760683930 UDZS5.1B-TE17 +C
D6026 00MHD20027010 HSS81TD-E 150V 150MA AXIAL TAPG.
D6027 00MHD20027010 HSS81TD-E 150V 150MA AXIAL TAPG.
D6028 20105001130AS 1SS133(HOMI)
D7001 20105001130AS 1SS133(HOMI)
D7002 20105001130AS 1SS133(HOMI)
D7003 20105001130AS 1SS133(HOMI)
D7004 20105001130AS 1SS133(HOMI)
D7007 00MHI10115210 SLR-342VRTB7 RED TAPING
D7008 00MHI10115210 SLR-342VRTB7 RED TAPING
D7009 20105001130AS 1SS133(HOMI)
D7010 20105001130AS 1SS133(HOMI)
D7011 20105001130AS 1SS133(HOMI)
D7012 20105001130AS 1SS133(HOMI)
D7013 20105001130AS 1SS133(HOMI)
D7014 20105001130AS 1SS133(HOMI)
D7017 20105001130AS 1SS133(HOMI)
D7018 20105001130AS 1SS133(HOMI)
D7019 20105001130AS 1SS133(HOMI)
D7020 20105001130AS 1SS133(HOMI)
D7021 20105001130AS 1SS133(HOMI)
D7022 20105001130AS 1SS133(HOMI)
D7023 20105001130AS 1SS133(HOMI)
D7024 20105001130AS 1SS133(HOMI)
D7025 00D2760683930 UDZS5.1B-TE17 +C
D7026 00MHD20027010 HSS81TD-E 150V 150MA AXIAL TAPG.
D7027 00MHD20027010 HSS81TD-E 150V 150MA AXIAL TAPG.
D7028 20105001130AS 1SS133(HOMI)
z
D8001 00D2760707007 FRH20A15
z
D8002 00D2760706008 FCH20A15
z
D8011 00MHD20055100 !SHOTTKY 11EQS10 1A 100V

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
