Marantz PM-11S3 Service Manual

76
8U-210120A ASS'Y
Ref No. Part No. Part Name Remark Q'ty New
SEMICONDUCTORS GROUP
D1001 26301000440AS SELG6E10C-S20 BLUE LED
D1002 00D3939607908 SLR342VC(TB7)
D1401 26301000440AS SELG6E10C-S20 BLUE LED
D1402 26301000440AS SELG6E10C-S20 BLUE LED
D1403 26301000440AS SELG6E10C-S20 BLUE LED
D1404 26301000440AS SELG6E10C-S20 BLUE LED
D1501 26301000440AS SELG6E10C-S20 BLUE LED
D1502 26301000440AS SELG6E10C-S20 BLUE LED
D1503 26301000440AS SELG6E10C-S20 BLUE LED
D1504 26301000440AS SELG6E10C-S20 BLUE LED
D1601 20105001130AS 1SS133(HOMI)
D1701 20105001130AS 1SS133(HOMI)
D1702 20105001130AS 1SS133(HOMI)
D1901 20105001130AS 1SS133(HOMI)
D6605 20105001230AS 1SS355T
D6606 20105001230AS 1SS355T
Q1001 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1002 00D2730464901 KTC3875S-GR-RTK/P
Q1003 00D2730464901 KTC3875S-GR-RTK/P
Q1004 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1005 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1012 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1013 00D2730464901 KTC3875S-GR-RTK/P
Q1014 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1016 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1017 00D2730464901 KTC3875S-GR-RTK/P
Q1018 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1019 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1020 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1021 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1022 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1023 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1401 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1402 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1403 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1404 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1501 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1502 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1503 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1504 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1601 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1602 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1603 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1606 00D2730464901 KTC3875S-GR-RTK/P
Q1607 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1608 00D2730464901 KTC3875S-GR-RTK/P
Q1701 00D2690192902 KRC102S-RTK/P (10K-10K)
Q1702 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1703 00D2710300904 KTA1266-GR-AT/P
Q1704 00D2730464901 KTC3875S-GR-RTK/P
Q1901 00D2690192902 KRC102S-RTK/P (10K-10K)

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
