Marantz PM-11S3 Service Manual

77
Ref No. Part No. Part Name Remark Q'ty New
Q1902 00D2690184907 KRA102S-RTK/P (10K-10K)
Q1903 00D2690192902 KRC102S-RTK/P (10K-10K)
Q6601 00D2710318909 2N5401S-RTK/P
Q6606 00D2710318909 2N5401S-RTK/P
Q6608 00D2710318909 2N5401S-RTK/P
Q6602 00D2730479909 2N5551S-RTK/P
Q6605 00D2730479909 2N5551S-RTK/P
Q6607 00D2730479909 2N5551S-RTK/P
U1001 997243101160M R5F100MFAFA UCOM *
U1002 00MHC10229210 BD4727G 2.7V RESET IC
U1004 00MHC008405K0 TC74VHC86FT EXOR
U1601 262010010000S R34ES9A-15MM(36KHZ) IR RECIVER
U1901 269010001700S PC817 PHOTO COUPLER
RESISTORS GROUP
R1701 00MGG05330160 33 OHM +- 5% 1/6W FLAMERETERDANT
R1902 00MGG05220160 22 OHM +- 5% 1/6W FLAMERETERDANT
R1912 00MGG05220160 22 OHM +- 5% 1/6W FLAMERETERDANT
CAPACITORS GROUP
C1019 00D2544213937 CE04W0J101MT (SRA)
C1020 00D2544213937 CE04W0J101MT (SRA)
C1027 00D2544196999 CE04W1H220MT (SRA)
C1028 00D2544303960 CE04W1E330MT(SRE)
C1034 00D2544299906 CE04W1C100MT(SRE)
C1042 00D2544213937 CE04W0J101MT (SRA)
C1401 00D2544299906 CE04W1C100MT(SRE)
C1402 00D2544299906 CE04W1C100MT(SRE)
C1403 00D2544299906 CE04W1C100MT(SRE)
C1404 00D2544299906 CE04W1C100MT(SRE)
C1501 00D2544299906 CE04W1C100MT(SRE)
C1502 00D2544299906 CE04W1C100MT(SRE)
C1503 00D2544299906 CE04W1C100MT(SRE)
C1504 00D2544299906 CE04W1C100MT(SRE)
C1601 00D2544213937 CE04W0J101MT (SRA)
C1603 00D2544213937 CE04W0J101MT (SRA)
C1708 00D2544299906 CE04W1C100MT(SRE)
C1904 00D2544299906 CE04W1C100MT(SRE)
C1912 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V)
OTHERS PARTS GROUP
K1901 643010084006S 2P PINJACK(RCA-206B)-NI-O
K1902 643010086002S MINI JACK(PJ-308-02)
K1903 643010086002S MINI JACK(PJ-308-02)
L1001 00MFC90020210 MLB-1608-1000A-N2
L1002 00MFC90020210 MLB-1608-1000A-N2
L1003 00MFC90020210 MLB-1608-1000A-N2
L1004 00MFC90020210 MLB-1608-1000A-N2
L1005 00MFC90020210 MLB-1608-1000A-N2
L1006 00MFC90020210 MLB-1608-1000A-N2
L1007 00MFC90020210 MLB-1608-1000A-N2
L1008 00MFC90020210 MLB-1608-1000A-N2
L1009 00MFC90020210 MLB-1608-1000A-N2

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
