Marantz PM-11S3 Service Manual

75
Ref No. Part No. Part Name Remark Q'ty New
Z6004 nsp GND TERMINAL FOR PCB
Z6501 nsp IRRAXTUBE V2 AWG20 BLACK 3MM
Z7001 nsp M3 SCREW TERMINAL
Z7002 nsp M3 SCREW TERMINAL
Z7003 nsp M3 SCREW TERMINAL
Z8001 nsp M3 SCREW TERMINAL
Z8002 nsp M3 SCREW TERMINAL
Z8003 nsp M3 SCREW TERMINAL
Z8004 nsp M3 SCREW TERMINAL
Z8005 nsp GND TERMINAL FOR PCB
Z8071 nsp M3 SCREW TERMINAL
Z8072 nsp M3 SCREW TERMINAL
Z8101 nsp GND TERMINAL FOR PCB
Z8501 nsp M3 SCREW TERMINAL
Z8502 nsp M3 SCREW TERMINAL
Z8503 nsp GND TERMINAL FOR PCB
Z9001 nsp M3 SCREW TERMINAL
Z9002 nsp M3 SCREW TERMINAL
Z9003 nsp M3 SCREW TERMINAL
Z9004 nsp M3 SCREW TERMINAL
Z9011 nsp SPK CONTACTOR
Z9012 nsp SPK CONTACTOR
Z9013 nsp SPK CONTACTOR
Z9014 nsp SPK CONTACTOR
Z9015 nsp SPK CONTACTOR
Z9016 nsp SPK CONTACTOR
Z9017 nsp SPK CONTACTOR
Z9018 nsp SPK CONTACTOR

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
