Marantz PM-11S3 Service Manual

74
Ref No. Part No. Part Name Remark Q'ty New
N6008 nsp 13P PLUG(C125Z1)
N6009 00MYP07005670 IMSA-6065B-06Z065-PT1
N6010 00MYP07005670 IMSA-6065B-06Z065-PT1
N6011 00MYP07005670 IMSA-6065B-06Z065-PT1
N7001 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N7002 00MYP07005670 IMSA-6065B-06Z065-PT1
N7003 00MYP07005670 IMSA-6065B-06Z065-PT1
N7004 nsp B2B-EH
N7005 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N7006 nsp B3B-PH-K-S (LF)(SN)
N7007 nsp 13P PLUG(C125Z1)
N7008 nsp 13P PLUG(C125Z1)
N7009 00MYP07005670 IMSA-6065B-06Z065-PT1
N7010 00MYP07005670 IMSA-6065B-06Z065-PT1
N7011 00MYP07005670 IMSA-6065B-06Z065-PT1
N8001 nsp CONNECTOR 2P B3P-VH
N8003 nsp CONNECTOR 2P B3P-VH
N8005 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N8006 nsp B6B-PH-K-S (LF)(SN)
N8007 nsp B9B-PH-K-S (LF)(SN)
N8008 nsp B3B-PH-K-S (LF)(SN)
N8101 nsp
B6B-EH-TS (LF)(SN) 6P RADIAL TAPING
JST
N8102 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N8103 nsp 15P PLUG(C125Z1)
N8104 nsp JST 3P-PLUG B3P-VH P=3.96M/M
N8501 nsp CONNECTOR 2P B3P-VH
N8502 nsp CONNECTOR 2P B3P-VH
N8503 nsp CONNECTOR 2P B3P-VH
N8504 nsp B6B-PH-K-S (LF)(SN)
N8505 nsp B3B-PH-K-S (LF)(SN)
N9501 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N9502 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N9503 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N9504 nsp B6B-PH-K-S (LF)(SN)
z
S8501 68201002600AS FTR-H2AK006T-TH *
z
S8502 68201002600AS FTR-H2AK006T-TH *
S9001 00D2140209002 RELAY FTR-F1AD024V
S9002 00D2140209002 RELAY FTR-F1AD024V
S9003 00D2140209002 RELAY FTR-F1AD024V
S9004 00D2140209002 RELAY FTR-F1AD024V
S9005 00D2140208003 RELAY(NA24W-K)
z
T8501 10101014200AM SUB TRANS (N) A363 N, K *
z
T8501 10101014300AM SUB TRANS (F) A363 F *
z
T8501 10101014400AM SUB TRANS (U) A363 U *
V6001 00MRA02220760 2.2KOHM NVZ6THT B222
V6002 00MRA02220760 2.2KOHM NVZ6THT B222
V7001 00MRA02220760 2.2KOHM NVZ6THT B222
V7002 00MRA02220760 2.2KOHM NVZ6THT B222
Z6001 nsp M3 SCREW TERMINAL
Z6002 nsp M3 SCREW TERMINAL
Z6003 nsp M3 SCREW TERMINAL

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
