Marantz PM-11S3 Service Manual

73
Ref No. Part No. Part Name Remark Q'ty New
C8011 00MOA10605020 10 UF M 50V RA-2
C8012 00D2544577974 CE04W1C471MT(RA3)
C8015 00MOA10702520 100 UF M 25V RA-2
C8016 00MOA10702520 100 UF M 25V RA-2
C8017 00MOA47602520 47 UF M 25V RA-2
C8101 00MOA15905010 LKG1H153MESBZT
C8102 00MOA15905010 LKG1H153MESBZT
C8103 00MOA476025Z0 ROS-25V 470M - G3#PE - T2 (47UF 25V)
C8104 00MOA476025Z0 ROS-25V 470M - G3#PE - T2 (47UF 25V)
C8105 00MOA227025R0 ROA-25V 221M -H5#PE - T2 (220UF 25V)
C8106 00MOA227025R0 ROA-25V 221M -H5#PE - T2 (220UF 25V)
C8107 00MOA22703520 220UF 35V M RA-2
C8108 00MOA476025Z0 ROS-25V 470M - G3#PE - T2 (47UF 25V)
C8109 00MOA227025R0 ROA-25V 221M -H5#PE - T2 (220UF 25V)
z
C8501 133750061200S #PHE840MA5100MA01R05
z
C8502 133750061200S #PHE840MA5100MA01R05
C8503 00D2544573949 CE04W1H010MT(RA3)
C8504 00D2544578724 CE04W1C332MC(RA3)
C8505 00D2544577945 CE04W1C101MT(RA3)
C8507 00D2544577961 CE04W1C331MT(RA3)
C8508 00D2544577974 CE04W1C471MT(RA3)
C9001 00MOF55103580 0.01UF 100V +- 5% FNS N, K
C9002 00MOF55103580 0.01UF 100V +- 5% FNS N, K
C9003 00MOF55393580 0.039UF 100V +- 5% FAS
C9004 00MOF55393580 0.039UF 100V +- 5% FAS
C9008 00MOA107025Z0 ROS-25V 101M - H4#PE - T2 (100UF 25V)
C9025 00MOA106035Z0 ROS-35V 100M - F3#PE - T2 (10UF 35V)
OTHERS PARTS GROUP
z
F8510 0520100170060 # T5A L 250V 0218005.MXP N, K
z
F8510 0520100200020 0218010.MXP F, U
H8511 nsp FUSE CLIP(TAPE)
H8512 nsp FUSE CLIP(TAPE)
L8003 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8004 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8005 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8006 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8007 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8101 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8102 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8503 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8504 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8505 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8507 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8508 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
L8509 00MFC90050130 BL02RN2-R62T2 FERRITE BEAD
N6001 nsp B4B-EH-TS (LF)(SN) 4P RADIAL TAPING
N6002 00MYP07005670 IMSA-6065B-06Z065-PT1
N6003 00MYP07005670 IMSA-6065B-06Z065-PT1
N6004 nsp B2B-EH
N6005 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING
N6006 nsp B3B-PH-K-S (LF)(SN)
N6007 nsp 13P PLUG(C125Z1)

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
