Marantz PM-11S3 Service Manual

72
Ref No. Part No. Part Name Remark Q'ty New
z
R8015 00MBF68400016 ! 0.68UF/4.7OHM
z
R8019 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R8022 00MGG05220160 22 OHM +- 5% 1/6W FLAMERETERDANT
z
R8028 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
R8101 00D2412471908 RD14B2E223JT(AMRS)
R8102 00D2412471908 RD14B2E223JT(AMRS)
z
R8108 00MGG05033160 3.3 OHM +- 5% 1/6W FLAMERETERDANT
z
R8109 00MGG05033160 3.3 OHM +- 5% 1/6W FLAMERETERDANT
z
R8114 00MGG05033160 3.3 OHM +- 5% 1/6W FLAMERETERDANT
z
R8120 00MGG05010120 ERD50FJ1R0P or SPRX1CM12.5A J 1R0 FLAMERETERDANT
z
R8121 00MGG05010120 ERD50FJ1R0P or SPRX1CM12.5A J 1R0 FLAMERETERDANT
z
R8122 00MBF68400010 ! 0.68UF/4.7OHM
z
R8501 00MNQ15022070 !2.2 OHM 7W W/TEMP.FUSE
z
R8502 00MNQ15022070 !2.2 OHM 7W W/TEMP.FUSE
z
R8504 00MBF68400016 ! 0.68UF/4.7OHM
z
R9001 00MNK05100020 10 OHM +- 5% 2W
z
R9002 00MNK05100020 10 OHM +- 5% 2W
R9005 00MNK05331020 330 OHM +- 5% 2W
R9006 00MNK05331020 330 OHM +- 5% 2W
R9007 00MGG05220160 22 OHM +- 5% 1/6W FLAMERETERDANT
R9008 00MGG05220160 22 OHM +- 5% 1/6W FLAMERETERDANT
R9011 00MGG05220160 22 OHM +- 5% 1/6W FLAMERETERDANT
CAPACITORS GROUP
C6001 00MOA106035Z0 ROS-35V 100M - F3#PE - T2 (10UF 35V)
C6002 00MOB47708050 470UF/80V NICHICON PB-FREE
C6003 00MOB47708050 470UF/80V NICHICON PB-FREE
C6004 00MOF55102580 1000PF 100V FNS
C6005 00MOF56681540 STAR(126)100VDC681J4-10
C6006 00MOA107025Z0 ROS-25V 101M - H4#PE - T2 (100UF 25V)
C6007 00MOA227025R0 ROA-25V 221M -H5#PE - T2 (220UF 25V)
C6010 00MOF55103580 0.01UF 100V +- 5% FNS
C6011 00D2544573936 CE04W1HR47MT(RA3)
C6013 133050078441S CQ93P2D220K(FAS)
C6014 133050078441S CQ93P2D220K(FAS)
C6015 133050078441S CQ93P2D220K(FAS)
C6016 133050078441S CQ93P2D220K(FAS)
C7001 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V)
C7002 00MOB47708050 470UF/80V NICHICON PB-FREE
C7003 00MOB47708050 470UF/80V NICHICON PB-FREE
C7004 00MOF55102580 1000PF 100V FNS
C7005 00MOF56681540 STAR(126)100VDC681J4-10
C7006 00MOA107025Z0 ROS-25V 101M - H4#PE - T2 (100UF 25V)
C7007 00MOA227025R0 ROA-25V 221M -H5#PE - T2 (220UF 25V)
C7010 00MOF55103580 0.01UF 100V +- 5% FNS
C7011 00D2544573936 CE04W1HR47MT(RA3)
C8001 00MOA10605020 10 UF M 50V RA-2
C8002 00D2544573949 CE04W1H010MT(RA3)
C8003 00D2544576700 CE04W1V222MC(RA3)
C8005 00MOA22703520 220UF 35V M RA-2
C8006 00MOA106035Z0 ROS-35V 100M - F3#PE - T2 (10UF 35V)
C8007 00MOA22703520 220UF 35V M RA-2
C8010 00MOA10702520 100 UF M 25V RA-2

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
