Marantz PM-11S3 Service Manual

71
Ref No. Part No. Part Name Remark Q'ty New
z
R6046 00MGG05102160 1K OHM +- 5% 1/6W FLAMERETERDANT
z
R6047 00MGG05470160 47 OHM +- 5% 1/6W FLAMERETERDANT
z
R6048 00MGG05470160 47 OHM +- 5% 1/6W FLAMERETERDANT
z
R6049 00MGG05221160 220 OHM +- 5% 1/6W FLAMERETERDANT
z
R6050 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R6051 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R6052 00MGO05001050 0.1 OHMS +-5% 5W PBR58
z
R6053 00MGO05001050 0.1 OHMS +-5% 5W PBR58
R6056 00MGG05152160 1.5K OHM +- 5% 1/6W FLAMERETERDANT
R6057 00MGG05152160 1.5K OHM +- 5% 1/6W FLAMERETERDANT
R6058 00MGG05472160 4.7K OHM +- 5% 1/6W FLAMERETERDANT
R6064 00MNK05101010 100 OHM +- 5% 1W
R6065 00MNK05331020 330 OHM +- 5% 2W
R6066 00MNK05101010 100 OHM +- 5% 1W
R6067 00MNK05331020 330 OHM +- 5% 2W
z
R6501 00D2790034054 PTH9M04BC222TS2F333
R7001 00D2412472965 RD14B2E104JT(AMRS)
R7002 00D2412463903 RD14B2E100JT(AMRS)
R7003 00D2412471908 RD14B2E223JT(AMRS)
R7004 00D2412467941 RD14B2E681JT(AMRS)
z
R7012 00MGG05471160 470 OHM +- 5% 1/6W FLAMERETERDANT
z
R7013 00MGG05471160 470 OHM +- 5% 1/6W FLAMERETERDANT
z
R7014 00MGG05181160 180 OHM +- 5% 1/16W FLAMERETERDANT
z
R7015 00MGG05181160 180 OHM +- 5% 1/16W FLAMERETERDANT
R7017 00D2412474921 RD14B2E474JT(AMRS)
R7020 00D2412467983 RD14B2E102JT(AMRS)
R7021 00D2412467983 RD14B2E102JT(AMRS)
R7023 00D2412465927 RD14B2E820JT(AMRS)
R7024 00D2412465927 RD14B2E820JT(AMRS)
R7027 00D2412463903 RD14B2E100JT(AMRS)
R7035 00D2412472965 RD14B2E104JT(AMRS)
z
R7042 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R7043 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R7044 00MGG05101160 100 OHM +- 5% 1/6W FLAMERETERDANT
z
R7045 00MGG05101160 100 OHM +- 5% 1/6W FLAMERETERDANT
z
R7046 00MGG05102160 1K OHM +- 5% 1/6W FLAMERETERDANT
z
R7047 00MGG05470160 47 OHM +- 5% 1/6W FLAMERETERDANT
z
R7048 00MGG05470160 47 OHM +- 5% 1/6W FLAMERETERDANT
z
R7049 00MGG05221160 220 OHM +- 5% 1/6W FLAMERETERDANT
z
R7050 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R7051 00MGG05100160 10 OHM +- 5% 1/6W FLAMERETERDANT
z
R7052 00MGO05001056 0.1 OHMS +-5% 5W PBR58
z
R7053 00MGO05001056 0.1 OHMS +-5% 5W PBR58
R7056 00MGG05152160 1.5K OHM +- 5% 1/6W FLAMERETERDANT
R7057 00MGG05152160 1.5K OHM +- 5% 1/6W FLAMERETERDANT
R7058 00MGG05472160 4.7K OHM +- 5% 1/6W FLAMERETERDANT
R7064 00MNK05101010 100 OHM +- 5% 1W
R7065 00MNK05331020 330 OHM +- 5% 2W
R7066 00MNK05101010 100 OHM +- 5% 1W
R7067 00MNK05331020 330 OHM +- 5% 2W
z
R7501 00D2790034054 PTH9M04BC222TS2F333
z
R8001 00MBF68400016 ! 0.68UF/4.7OHM
z
R8014 00MGG05010120 ERD50FJ1R0P or SPRX1CM12.5A J 1R0 FLAMERETERDANT

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
