Marantz PM-11S3 Service Manual

57
Ref No. Part No. Part Name Remark Q'ty New
Q4014 00MHX113121B0 2SA1312 (B)
Q4015 00MHX333241B0 2SC3324 (B)
Q4016 00MHX333241B0 2SC3324 (B)
Q4017 00D2710300904 KTA1266-GR-AT/P
Q4018 00D2710300904 KTA1266-GR-AT/P
Q4019 21305001240AS KTC3198-GR-AT/P
Q4020 21305001240AS KTC3198-GR-AT/P
Q4021 00D2710300904 KTA1266-GR-AT/P
Q4022 00D2710300904 KTA1266-GR-AT/P
Q4023 21305001240AS KTC3198-GR-AT/P
Q4024 21305001240AS KTC3198-GR-AT/P
Q4025 00D2710300904 KTA1266-GR-AT/P
Q4026 00D2710300904 KTA1266-GR-AT/P
Q4027 21305001240AS KTC3198-GR-AT/P
Q4028 21305001240AS KTC3198-GR-AT/P
Q4031 00D2710300904 KTA1266-GR-AT/P
Q4032 00D2710300904 KTA1266-GR-AT/P
Q4033 21305001240AS KTC3198-GR-AT/P
Q4034 21305001240AS KTC3198-GR-AT/P
Q4035 00D2710300904 KTA1266-GR-AT/P
Q4036 00D2710300904 KTA1266-GR-AT/P
Q4037 21305001240AS KTC3198-GR-AT/P
Q4038 21305001240AS KTC3198-GR-AT/P
Q4039 00D2710300904 KTA1266-GR-AT/P
Q4040 00D2710300904 KTA1266-GR-AT/P
Q4041 21305001240AS KTC3198-GR-AT/P
Q4042 21305001240AS KTC3198-GR-AT/P
Q4043 00D2710300904 KTA1266-GR-AT/P
Q4044 00D2710300904 KTA1266-GR-AT/P
Q4045 21305001240AS KTC3198-GR-AT/P
Q4046 21305001240AS KTC3198-GR-AT/P
Q4507 00D2710300904 KTA1266-GR-AT/P
Q4508 00D2710300904 KTA1266-GR-AT/P
Q4509 21305001240AS KTC3198-GR-AT/P
Q4510 21305001240AS KTC3198-GR-AT/P
Q4511 00D2710300904 KTA1266-GR-AT/P
Q4512 00D2710300904 KTA1266-GR-AT/P
Q4513 00D2710300904 KTA1266-GR-AT/P
Q4514 00D2710300904 KTA1266-GR-AT/P
Q4515 21305001240AS KTC3198-GR-AT/P
Q4516 21305001240AS KTC3198-GR-AT/P
Q4517 21305001240AS KTC3198-GR-AT/P
Q4518 21305001240AS KTC3198-GR-AT/P
Q4519 00D2710300904 KTA1266-GR-AT/P
Q4520 00D2710300904 KTA1266-GR-AT/P
Q4521 21305001240AS KTC3198-GR-AT/P
Q4522 21305001240AS KTC3198-GR-AT/P
Q4523 21305001240AS KTC3198-GR-AT/P
Q4524 21305001240AS KTC3198-GR-AT/P
Q4525 00D2710300904 KTA1266-GR-AT/P
Q4526 00D2710300904 KTA1266-GR-AT/P
Q5001 00D2710300904 KTA1266-GR-AT/P
Q5002 00D2710300904 KTA1266-GR-AT/P

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
