Marantz PM-11S3 Service Manual

58
Ref No. Part No. Part Name Remark Q'ty New
Q5003 21305001240AS KTC3198-GR-AT/P
Q5004 21305001240AS KTC3198-GR-AT/P
Q5005 00D2710300904 KTA1266-GR-AT/P
Q5006 00D2710300904 KTA1266-GR-AT/P
Q5007 00D2710300904 KTA1266-GR-AT/P
Q5008 00D2710300904 KTA1266-GR-AT/P
Q5009 21305001240AS KTC3198-GR-AT/P
Q5010 21305001240AS KTC3198-GR-AT/P
Q5011 21305001240AS KTC3198-GR-AT/P
Q5012 21305001240AS KTC3198-GR-AT/P
Q5501 00D2710300904 KTA1266-GR-AT/P
Q5502 00D2710300904 KTA1266-GR-AT/P
Q5503 21305001240AS KTC3198-GR-AT/P
Q5504 21305001240AS KTC3198-GR-AT/P
Q5505 00D2710300904 KTA1266-GR-AT/P
Q5506 00D2710300904 KTA1266-GR-AT/P
Q5507 00D2710300904 KTA1266-GR-AT/P
Q5508 00D2710300904 KTA1266-GR-AT/P
Q5509 21305001240AS KTC3198-GR-AT/P
Q5510 21305001240AS KTC3198-GR-AT/P
Q5511 21305001240AS KTC3198-GR-AT/P
Q5512 21305001240AS KTC3198-GR-AT/P
Q5513 00D2690192902 KRC102S-RTK/P (10K-10K)
Q5515 00MHX113121B0 2SA1312 (B)
Q5516 00MHX113121B0 2SA1312 (B)
Q5517 00MHX113121B0 2SA1312 (B)
Q5518 00MHX113121B0 2SA1312 (B)
Q5519 00MHX333241B0 2SC3324 (B)
Q5520 00MHX333241B0 2SC3324 (B)
Q5521 00MHX333241B0 2SC3324 (B)
Q5522 00MHX333241B0 2SC3324 (B)
Q5523 00MHX333241B0 2SC3324 (B)
Q5524 00MHX333241B0 2SC3324 (B)
Q5525 00MHX333241B0 2SC3324 (B)
Q5526 00MHX333241B0 2SC3324 (B)
Q5527 00MHX113121B0 2SA1312 (B)
Q5528 00MHX113121B0 2SA1312 (B)
Q5529 00MHX113121B0 2SA1312 (B)
Q5530 00MHX113121B0 2SA1312 (B)
D1751 00MHI10005980 NSPW515BS-S-CO
D2003 20105001130AS 1SS133(HOMI)
D2004 00D2760683998 UDZS16B-TE17 +C
D2005 20105001130AS 1SS133(HOMI)
D3501 20105001130AS 1SS133(HOMI)
D3502 20105001130AS 1SS133(HOMI)
D3503 20105001130AS 1SS133(HOMI)
D3504 20105001130AS 1SS133(HOMI)
D3505 20105001130AS 1SS133(HOMI)
D3506 20105001130AS 1SS133(HOMI)
D3507 20105001130AS 1SS133(HOMI)
D3508 20105001130AS 1SS133(HOMI)
D3601 20105001130AS 1SS133(HOMI)
D3602 20105001130AS 1SS133(HOMI)

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
