Marantz PM-11S3 Service Manual

59
Ref No. Part No. Part Name Remark Q'ty New
D3801 20105001130AS 1SS133(HOMI)
D3802 20105001130AS 1SS133(HOMI)
D3901 20105001230AS 1SS355T
D3902 20105001230AS 1SS355T
D3903 20105001230AS 1SS355T
D3904 20105001230AS 1SS355T
D3905 20105001230AS 1SS355T
D3906 20105001230AS 1SS355T
D4001 20105001130AS 1SS133(HOMI)
D4003 20105001130AS 1SS133(HOMI)
D4004 20105001130AS 1SS133(HOMI)
D4005 20105001130AS 1SS133(HOMI)
D4006 20105001130AS 1SS133(HOMI)
D4007 20105001130AS 1SS133(HOMI)
D4008 20105001130AS 1SS133(HOMI)
D4009 20105001130AS 1SS133(HOMI)
D4010 20105001130AS 1SS133(HOMI)
D4011 20105001130AS 1SS133(HOMI)
D4012 20105001130AS 1SS133(HOMI)
D4013 20105001130AS 1SS133(HOMI)
D4014 20105001130AS 1SS133(HOMI)
D4015 00MHI10115210 SLR-342VRTB7 RED TAPING
D4016 00MHI10115210 SLR-342VRTB7 RED TAPING
D4017 00MHI10115210 SLR-342VRTB7 RED TAPING
D4018 00MHI10115210 SLR-342VRTB7 RED TAPING
D4019 20105001130AS 1SS133(HOMI)
D4020 20105001130AS 1SS133(HOMI)
D4021 20105001130AS 1SS133(HOMI)
D4022 20105001130AS 1SS133(HOMI)
D4023 20105001130AS 1SS133(HOMI)
D4024 20105001130AS 1SS133(HOMI)
D4025 20105001130AS 1SS133(HOMI)
D4026 20105001130AS 1SS133(HOMI)
D4027 20105001130AS 1SS133(HOMI)
D4028 20105001130AS 1SS133(HOMI)
D4029 20105001130AS 1SS133(HOMI)
D4030 20105001130AS 1SS133(HOMI)
D4501 00MHI10115210 SLR-342VRTB7 RED TAPING
D4502 00MHI10115210 SLR-342VRTB7 RED TAPING
D4503 00MHI10115210 SLR-342VRTB7 RED TAPING
D4504 00MHI10115210 SLR-342VRTB7 RED TAPING
D5001 00MHI10115210 SLR-342VRTB7 RED TAPING
D5002 00MHI10115210 SLR-342VRTB7 RED TAPING
D5003 00MHI10115210 SLR-342VRTB7 RED TAPING
D5004 00MHI10115210 SLR-342VRTB7 RED TAPING
D5005 20105001130AS 1SS133(HOMI)
D5501 00MHI10115210 SLR-342VRTB7 RED TAPING
D5502 00MHI10115210 SLR-342VRTB7 RED TAPING
D5503 00MHI10115210 SLR-342VRTB7 RED TAPING
D5504 00MHI10115210 SLR-342VRTB7 RED TAPING
D5505 20105001130AS 1SS133(HOMI)
D5506 20105001130AS 1SS133(HOMI)
D5513 20105001230AS 1SS355T

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
