Marantz PM-11S3 Service Manual

42
Ref No. Part No. Part Name Remarks Q'ty New
005B 00M04AJ251010 BADGE (MARANTZ) 1
005K nsp CONTACTER 1
006B 00M256J355032 IR LENS N1G, FN, K1G 1
006B 00M256J355043 IR LENS (BL) A363 N1B, U1B 1 *
006D nsp RETAINER TOPCOVER REAR CP 1
006G nsp STOPPER 1
006K nsp SHEET FOR CHEMICON RETAINER 001K 4
006L nsp TR COVER 4
007B nsp FRONT MOLD CHASSIS PM11S3 A363 1
008B nsp LCD HOLDER 1
008D 43731001801AM TOP COVER NET GL PM-11S3 2 *
008D 43731001800AM TOP COVER NET BL PM-11S3 N1B, U1B 2 *
009B nsp LCD MASK 1
009G nsp TRANS SPACER 1
010D 00M04AJ107060 SHEET PET 370X10 T0.1 1
011B nsp HEAD PHONE BRACKET 1
011D 00M04AJ107080 SHEET PET 175X5 T0.1 2
011G nsp LEFT SIDE BRACKET 1
012D nsp TOPCOVER REAR SHEET 3
013D 40441004201AM SIDE PANEL ASSY GL PM-11S3 N1G, FN, K1G 1 *
013D 40441004200AM SIDE PANEL ASSY BL PM-11S3 N1B, U1B 1 *
015B 42341002307AM INDICATOR BL A1070P T0.5 PM-11S3 A363 1 *
016B 00M04AJ056110 LCD ESC.BUFFER 1
017B 42351003200AM LENS LCD ESC. PM-11S3 2 *
017G nsp RIGHT SIDE BRACKET 1
018B 00M04AJ303020 LCD LENS MASK 2
019B 00M04AJ303030 SIDE LENS LED MASK 2
019D 544510081006M LABEL (HOT SURFACE CAUTION) 1
020B 00M04AJ355032 LENS SIDE 2
020G nsp NIFCO PWB HOLDER #735 66NYLON 1
021B 00M04AJ056022 SIDE LENS BUFFER 2
021D nsp SPACER 1
023B nsp FRONT METAL CHASSIS 1
023G nsp DIODE SHIELD 1
025G nsp CENTER SHIELD 1
027B 00M04AJ063110 SIDE ESC.(L/GL) 1
027B 00M04AJ063020 SIDE ESC.(L/BL) PM-11S3 A363 1 *
027G nsp PRE DIODE HEATSINK 1
029B 00M04AJ063130 SIDE ESC.(R/GL) PM-11S3 A363 N1G, FN, K1G 1 *
029B 00M04AJ063030 SIDE ESC.(R/BL) PM-11S3 A363 N1B, U1B 1 *
031B 00M04AJ259210 FUNCTION BUTTON BUSH GOLD N1G, FN, K1G 8
031B 00M04AJ259010 BUTTON BUSH BLACK N1B, U1B 8
032B 00M04AJ270140 FUNCTION BUTTON MILKY GL N1G, FN, K1G 6 *
032B 00M04AJ270040 FUNCTION BUTTON MILKY BL N1B, U1B 6 *
033B 00M04AJ270130 FUNCTION BUTTON (GL) N1G, FN, K1G 2
033B 00M04AJ270030 FUNCTION BUTTON BLACK N1B, U1B 2
035B 00M04AJ353112 RING MASTER KNOB GL N1G, FN, K1G 2
035B 00M04AJ353012 RING MASTER KNOB BL N1B, U1B 2
036B 00M10AJ154110 MASTER KNOB (GL) N1G, FN, K1G 2
036B 00M10AJ154010 VOLUME KNOB BLACK N1B, U1B 2
036G nsp CHASSIS L SIDE SHEET 1
037B 00M04AJ270110 POWER BUTTON (GL) N1G, FN, K1G 1
037B 00M04AJ270010 POWER BUTTON BLACK N1B, U1B 1

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
