UCOM STBY
UCOM STBY PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The s
y
mbols in the column Remarks indicate the followin
g
destinations.
U : North America model N : Euro
p
e model K : China model F : Ja
p
an model
B : Black model SG : Silver
g
old model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1251-1262 20105001230AS 1SS355T 20105001230AS 12
D1601 20105001130AS 1SS133(HOMI) 20105001130AS 1
D1901 00D3939607908 SLR342VC(TB7) 00D3939607908 1
D2501-2506 26301000440AS SELG6E10C-S20 BLUE LED 26301000440AS 6
D2507 263010041403S SLI-343V8RC(T32) 263010041403S 1
D2508-2511 176010009406S SELK2E14C-D BLUE LED 176010009406S 4
D8501-8506 20305002730AS 1N4003(HOMI) 20305002730AS 6
D8507 00D2760683985 UDZS11B-TE17 00D2760683985 1
D8508 20105001130AS 1SS133(HOMI) 20105001130AS 1
! D8509-8512 00MHD20055101 !SHOTTKY 11EQS10 1A 100V 00MHD20055101 4
D8513-8518 20305002730AS 1N4003(HOMI) 20305002730AS 6
D8530 00D2760683901 UDZS5.6B-TE17 +C 00D2760683901 1
Q1001,1002 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 2
Q1003,1004 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 2
Q1005-1009 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 5
Q1010 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1011 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q1012 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1013 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q1014 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1030,1031 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 2
Q1251,1252 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 2
Q1601-1603 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 3
Q1604 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q1801 00MHT600141B1 KTA1271 PNP TRANSISTOR RANK=Y 00MHT600141B1 1
Q1802 00MHT800951B1 KTC3203 NPN TRANSISTOR RANK=Y 00MHT800951B1 1
Q1803 00MHT600141B1 KTA1271 PNP TRANSISTOR RANK=Y 00MHT600141B1 1
Q1804 00MHT800951B1 KTC3203 NPN TRANSISTOR RANK=Y 00MHT800951B1 1
Q2501-2504 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 4
Q8501 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q8502 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q8503 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
! Q8530 00MHT348832A0 TRANSISTOR 2SC4883 O OR Y 00MHT348832A0 1
U1001 9R2481021100M PM8005 ROM ASSY (TMP86FH47BUG) 8R2481021100M 1 6
U1002 235010049402S KIA7042AP-AT/P 4.2V RESET IC 235010049402S 1
U1003 00MHC1043399Z AT24C08BN-SH-T 00MHC1043399Z 1
U2001-2004 23281004150AS NJM8080G 23281004150AS 4 *
U2601 262010010000S R34ES9A-15MM(36KHZ) IR RECIVER 262010010000S 1
! U8501 00D2622977933 BA50BC0FP-E2 00D2622977933 1
RESISTOR GROUP
R1001,1002 nsp RM73B--473JT +1608 00D2472011942 2
R1003 nsp RM73B--104JT +1608 00D2472012925 1
R1004 nsp RM73B--105JT +1608 00D2472014965 1
R1005 nsp RM73B--333JT +1608 00D2472011900 1
R1006 nsp RM73B--332JT +1608 00D2472008968 1
R1007 nsp RM73B--103JT +1608 00D2472009983 1
R1008-1012 nsp RM73B--473JT +1608 00D2472011942 5
R1013 nsp RM73B--104JT +1608 00D2472012925 1
R1014 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1015-1017 nsp RM73B--103JT +1608 00D2472009983 3
R1018 nsp RM73B--473JT +1608 00D2472011942 1
R1019 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1020 nsp RM73B--103JT +1608 00D2472009983 1
R1021 nsp RM73B--473JT +1608 00D2472011942 1
R1022 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1023-1026 nsp RM73B--473JT +1608 00D2472011942 4
R1027 nsp RM73B--223JT +1608 00D2472010969 1
R1035 nsp RM73B--103JT +1608 00D2472009983 1
R1251,1252 nsp RM73B--124JT +1608 00D2472012941 2
R1253-1255 nsp RM73B--103JT +1608 00D2472009983 3
R1256 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1257 nsp RM73B--152JT +1608 00D2472007985 1
R1258 nsp RM73B--392JT +1608 00D2472008984 1
R1259,1260 nsp RM73B--152JT +1608 00D2472007985 2
R1261 nsp RM73B--222JT +1608 00D2472008926 1
R1262 nsp RM73B--152JT +1608 00D2472007985 1
R1263 nsp RM73B--101JT +1608 00D2472005903 1
R1264 nsp RM73B--122JT +1608 00D2472007969 1
R1265 nsp RM73B--101JT +1608 00D2472005903 1
R1266,1267 nsp RM73B--222JT +1608 00D2472008926 2
R1268,1269 nsp RM73B--182JT +1608 00D2472008900 2
R1270 nsp RM73B--223JT +1608 00D2472010969 1
R1271 nsp RM73B--103JT +1608 00D2472009983 1
R1601 nsp RM73B--101JT +1608 00D2472005903 1
R1602 nsp RM73B--473JT +1608 00D2472011942 1
R1603 nsp RM73B--183JT +1608 00D2472010943 1
R1604 nsp RM73B--473JT +1608 00D2472011942 1
R1801,1802 nsp RM73B--222JT +1608 00D2472008926 2
R1803,1804 nsp RM73B--473JT +1608 00D2472011942 2
R1805 nsp RM73B--222JT +1608 00D2472008926 1
R1806 nsp RM73B--473JT +1608 00D2472011942 1
R1808 nsp RM73B--222JT +1608 00D2472008926 1
R1809 nsp RM73B--473JT +1608 00D2472011942 1
R1901,1902 nsp RM73B--102JT +1608 00D2472007943 2
R2001,2002 nsp RD14B2E333JT(5) 00D2412402919 2
R2003,2004 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 2
R2005,2006 nsp RD14B2E333JT(5) 00D2412402919 2
R2007-2010 nsp RD14B2E272JT(5) 00D2412399954 4
R2011,2012 nsp RD14B2E104JT(5) 00D2412403934 2
R2013,2014 nsp RD14B2E101JT(5) 00D2412396928 2
R2015,2016 nsp RD14B2E122JT(5) 00D2412398971 2
R2017,2018 nsp RD14B2E473JT(5) 00D2412402951 2
R2019,2020 nsp RD14B2E222JT(5) 00D2412399938 2
R2021,2022 nsp RD14B2E393JT(5) 00D2412402935 2
