Marantz PM8005 - Page 46

UCOM STBY
REF No. Part No. Part Name Remarks Q'ty New Ver
R2023,2024 nsp RD14B2E122JT(5) 00D2412398971 2
R2025,2026 nsp RD14B2E563JT(5) 00D2412402977 2
R2501 nsp RM73B--103JT +1608 00D2472009983 1
R2502 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2503 nsp RM73B--103JT +1608 00D2472009983 1
R2504 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2505 nsp RM73B--103JT +1608 00D2472009983 1
R2506 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2507 nsp RM73B--103JT +1608 00D2472009983 1
R2508 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2509 nsp RM73B--103JT +1608 00D2472009983 1
R2510 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2511 nsp RM73B--103JT +1608 00D2472009983 1
R2512 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2514 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2515 nsp RM73B--103JT +1608 00D2472009983 1
R2516 nsp RM73B--221JT +1608 00D2472005987 1
R2517 nsp RM73B--103JT +1608 00D2472009983 1
R2518 nsp RM73B--221JT +1608 00D2472005987 1
R2519 nsp RM73B--103JT +1608 00D2472009983 1
R2520 nsp RM73B--221JT +1608 00D2472005987 1
R2521 nsp RM73B--103JT +1608 00D2472009983 1
R2522 nsp RM73B--221JT +1608 00D2472005987 1
R2602 nsp RD14B2E101JT(5) 00D2412396928 1
R2701 nsp RM73B--103JT +1608 00D2472009983 1
R2702 nsp RM73B--222JT +1608 00D2472008926 1
R2703-2705 nsp RM73B--392JT +1608 00D2472008984 3
R2706 nsp RM73B--223JT +1608 00D2472010969 1
! R8501 00MGG0522016X 22 OHM +- 5% 1/6W 00MGG0522016X 1
R8502 nsp RM73B--823JT +1608 00D2472012909 1
R8503,8504 nsp RM73B--472JT (1608) +1608 00D2472009909 2
! R8505 00MBF68400016 ! 0.68UF/4.7OHM 00MBF68400016 1
! R8506,8507 00MGG05010120 ERD50FJ1R0P or SPRX1CM12.5A J 1R0 00MGG05010120 2
R8508 nsp RM73B--104JT +1608 00D2472012925 1
R8509 nsp RM73B--470JT +1608 00D2472004920 1
R8530 nsp RM73B--822JT +1608 00D2472009967 1
R8531 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 1
R9901,9902 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 2
CAPACIITORS GROUP
C1001,1002 nsp CK73F1E104ZT +1608 00D2570512903 2
C1003 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C1004 nsp CK73F1E104ZT +1608 00D2570512903 1
C1005 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C1006-1015 nsp CK73F1E104ZT +1608 00D2570512903 10
C1016 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 1
C1251 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C1601 00D2544302974 CE04W1A101MT(SRE) 00D2544302974 1
C1801,1802 00D2544573949 CE04W1H010MT(RA3) 00D2544573949 2
C1803 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C2001,2002 00MOA22605021 22 UF M 50V RA-2 00MOA22605021 2
C2003-2006 133050074500S CQ93M2E101J(LP) 133050074500S 4
C2007,2008 00MOA22605021 22 UF M 50V RA-2
00MOA22605021 2
C2009,2010 00MOA10702521 100 UF M 25V RA-2 00MOA10702521 2
C2011,2012 13305030640AS CQ93P2A103JT(DTN) 13305030640AS 2 Ver.5
C2013,2014 133050086503S CQ93M2A221JT(PEF) 133050086503S 2
C2015,2016 00D2561059938 CF93A1H334JT (JL) 00D2561059938 2
C2017,2018 13305030543AS CQ93P2A102JT(DTN) 13305030543AS 2 Ver.5
C2019,2020 00MEJ22505011 2.2UF/ 50V 00MEJ22505011 2
C2021,2022 13305030646AS CQ93P2A683JT(DTN) 13305030646AS 2 Ver.5
C2501 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C2502-2511 nsp CK73B1H103KT (1608) +1608 00D2570501901 10
C2602 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C2603 00D2544302974 CE04W1A101MT(SRE) 00D2544302974 1
C2701 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C2702 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C8501 00MOF55103581 0.01UF 100V +- 5% FNS 00MOF55103581 1
! C8502 133750061200S #PHE840MA5100MA01R05 133750061200S 1
C8503 00D2544573949 CE04W1H010MT(RA3) 00D2544573949 1
C8504 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C8505,8506 00MOC47803546 4700UF/35V NICHICON PB-FREE 00MOC47803546 2
C8507 13405013120AS CE04W1E222MC(KR3) 13405013120AS 1
C8509 00MOA22706326 220 UF M 63V RA-2 00MOA22706326 1
C8510-8512 nsp CK73F1E104ZT +1608 00D2570512903 3
C8513 13405012440AS CE04W0J221MT(KR3) 13405012440AS 1
C8514 nsp CK73F1E104ZT +1608 00D2570512903 1
C8515 00MOA47602521 47 UF M 25V RA-2 00MOA47602521 1
C8516 00D2544573949 CE04W1H010MT(RA3) 00D2544573949 1
C8517-8519 nsp CK73F1E104ZT +1608 00D2570512903 3
C8530 00MOA47602521 47 UF M 25V RA-2 00MOA47602521 1
! C8901 00D2538029713 CK45F2EAC471KC(KX) 00D2538029713 1
C9901,9902 00MOF55103581 0.01UF 100V +- 5% FNS N/K 00MOF55103581 2
OTHER PARTS GROUP
B1201 nsp 4P L=70 EH-SCN UL1430 AWG26 61205058100AS 1 *
B1801 nsp 3P L=160 EH-SCN UL1430 AWG26 61205058200AS 1 *
B1901 nsp EHR-SCN 2.5MMPICH DIP TYPE 3PIN 10CM 120106230070 1
B2002 nsp SIN-SRA 1PIN 16CM 612050090005M 1
B2003 nsp EHR-SCN 3P 150MM(SHIELD WIRE) 120500030070 1
B2004 nsp EHR-SCN 5PIN 17CM 612050088002M 1
B2701 nsp EHR-SCN 6PIN 14CM 612050092001M 1
B9901 nsp SIN-SRA 1PIN 11CM 612050089005M 1
! F8510 520100170060 # T5A L 250V 0218005.MXP F 520100170060 1
! F8520 520100150000 02183.15MXP N/K 520100150000 1
! F8520 520100180090 021806.3MXP (FUSE 6.3A 250V) U/F 520100180090 1
H8511,8512 nsp FUSE CLIP(TAPE) F 00D2020040909 2
H8521,8522 nsp FUSE CLIP(TAPE) 00D2020040909 2
! K8501 64105002800AS AC OUTLET (AC-181-UL-11H) F 64105002800AS 1
K8502 643010103006S RCA PIN JACK 2P NI MSP-242V1-24 643010103006S 1
K9901 00MYJ01005170 JY-6313_01-030 6.4D PHONE JACK 00MYJ01005170 1
L1001,1002 nsp MLB-1608-1000A-N2 00MFC9002021Y 2
L8501-8503 nsp MLB-1608-1000A-N2 00MFC9002021Y 3
N1001 nsp B10B-PH-K-S (LF)(SN) 00MYJ06006300 1
N1002 nsp S4B-EH 00MYP06003940 1
6
