Marantz PM8005 - Page 48

PHONO SPK
PHONO SPK PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The s
y
mbols in the column Remarks indicate the followin
g
destinations
U : North America model N : Euro
p
e model K : China model F : Ja
p
an mode
B : Black model SG : Silver
g
old mode
l
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4001-4016 20105001130AS 1SS133(HOMI) 20105001130AS 16
D7501-7503 20105001130AS 1SS133(HOMI) 20105001130AS 3
Q4001,4002 21105002140AS KSA992FTA 21105002140AS 2
Q4003,4004 21305002440AS KSC1845FTA 21305002440AS 2
Q4005,4006 21105002140AS KSA992FTA 21105002140AS 2
Q4007-4012 21305002440AS KSC1845FTA 21305002440AS 6
Q4013-4018 21105002140AS KSA992FTA 21105002140AS 6
Q4019,4020 21305002440AS KSC1845FTA 21305002440AS 2
Q4021,4022 21105002140AS KSA992FTA 21105002140AS 2
Q4023,4024 21305002440AS KSC1845FTA 21305002440AS 2
Q4025,4026 21105002140AS KSA992FTA 21105002140AS 2
Q4027-4030 21305002440AS KSC1845FTA 21305002440AS 4
Q4031,4032 21105002140AS KSA992FTA 21105002140AS 2
Q4033-4036 21305001240AS KTC3198-GR-AT/P 21305001240AS 4
Q4037-4042 00D2710300904 KTA1266-GR-AT/P 00D2710300904 6
Q4043,4044 21305001240AS KTC3198-GR-AT/P 21305001240AS 2
RESISTOR GROUP
R2901-2904 nsp RD14B2E224JT(5) 00D2412404917 4
R2907,2908 nsp RD14B2E102JT(5) 00D2412398955 2
R4001,4002 nsp RD14B2E682JT(5) N/K 00D2412400953 2
R4003,4004 nsp RD14B2E334JT(5) 00D2412404959 2
R4005,4006 nsp RD14B2E563JT(5) 00D2412402977 2
R4007,4008 nsp RD14B2E101JT(5) N/K 00D2412396928 2
R4007,4008 nsp RD14B2E330JT(5) U/F 00D2412395903 2
R4009,4010 nsp RD14B2E104JT(5) 00D2412403934 2
R4011-4014 nsp RD14B2E561JT(5) 00D2412397998 4
R4015-4018 nsp RD14B2E220JT(5) 00D2412394962 4
R4019,4020 nsp RD14B2E820JT(5) 00D2412396902 2
R4021-4024 nsp RD14B2E220JT(5) 00D2412394962 4
R4025,4026 nsp RD14B2E471JT(5) 00D2412397972 2
R4027,4028 nsp RD14B2E104JT(5) 00D2412403934 2
R4029,4030 nsp RD14B2E471JT(5) 00D2412397972 2
R4031-4034 nsp RD14B2E221JT(5) 00D2412397901 4
R4035,4036 nsp RD14B2E153JT(5) 00D2412401936 2
R4037-4040 nsp RD14B2E220JT(5) 00D2412394962 4
R4041,4042 nsp RD14B2E153JT(5) 00D2412401936 2
R4043-4046 nsp RD14B2E100JT(5) 00D2412393989 4
R4047,4048 nsp RD14B2E104JT(5) 00D2412403934 2
R4049,4050 nsp RD14B2E682JT(5) 00D2412400953 2
R4051,4052 nsp RD14B2E564JT(5) 00D2412405916 2
R4053,4054 nsp RD14B2E101JT(5) 00D2412396928 2
R4055-4060 nsp RD14B2E220JT(5) 00D2412394962 6
R4061,4062 nsp RD14B2E473JT(5) 00D2412402951 2
R4063-4066 nsp RD14B2E220JT(5) 00D2412394962 4
R4067-4070 nsp RD14B2E473JT(5) 00D2412402951 4
! R4071-4074 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 4
R4075,4076 nsp RD14B2E104JT(5) 00D2412403934 2
R4077,4078 nsp RD14B2E101JT(5) 00D2412396928 2
! R7501,7502 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 2
R7503,7504 00MNK05331020 330 OHM +- 5% 2W 00MNK05331020 2
R7505 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 1
! R7511,7512 1240500010030 MOS2CL15A100J10OHM +-5% 2W 1240500010030 2
CAPACIITORS GROUP
C2907,2908 133050086510S CQ93M2A471JT(PEF) 133050086510S 2
C2909,2910 00MDD38104011 50V DC 0.1UF +80 -20% 00MDD38104011 2
C4000 00MDD38104011 50V DC 0.1UF +80 -20% 00MDD38104011 1
C4001,4002 00MOF55221591 220PF 200V +- 10% FAS N/K 00MOF55221591 2
C4003,4004 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 2
C4005,4006 00MOF55101591 100PF 200V +- 10% FAS 00MOF55101591 2
C4007,4008 133050125415S CQ93E2A821JT(FNS) 133050125415S 2
C4009,4010 00MOF55332581 3300PF 100V FNS 00MOF55332581 2
C4011,4012 00MOF55102581 1000PF 100V FNS 00MOF55102581 2
C4013,4014 00MOF55393586 0.039UF 100V +- 5% FAS 00MOF55393586 2
C4015,4016 00MOF55103581 0.01UF 100V +- 5% FNS 00MOF55103581 2
C4017,4018 00D2544578711 CE04W1C222MC(RA3) 00D2544578711 2
C4019-4022 00MOA227025R1 ROA-25V 221M -H5#PE - T2 (220UF 25V) 00MOA227025R1 4
C4023,4024 00MOA106035Z1 ROS-35V 100M - F3#PE - T2 (10UF 35V) 00MOA106035Z1 2
C5901 00MOF55103581 0.01UF 100V +- 5% FNS 00MOF55103581 1
C7501,7502 00MOF55103581 0.01UF 100V +- 5% FNS N/K 00MOF55103581 2
C7503,7504 00MOA225100Z1 ROS-100V2R2 F3#PE-T2 00MOA225100Z1 2
C7509 00MOA225100Z1 ROS-100V2R2 F3#PE-T2 00MOA225100Z1 1
C7511,7512 00MOF55393586 0.039UF 100V +- 5% FAS 00MOF55393586 2
OTHER PARTS GROUP
B2901 nsp EHR-SCN 2.5MMPICH DIP TYPE 6PIN 8CM 120105770050 1
B4001 nsp EHR-SCN 2.5MMPICH DIP TYPE 5PIN 8CM 120105920040 1
K2901,2902 643810029001S RCA PIN JACK 2P AU MSP-242V3-12 GILT LF 643810029001S 2
K4001 643810029001S RCA PIN JACK 2P AU MSP-242V3-12 GILT LF 643810029001S 1
L4001,4002 00MLC13240010 320 MH CHOKE COIL (TOROIDAL) N/K 00MLC13240010 2
N5901 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING 00MYP0600383X 1
N5902 nsp 13P SOCKET(C125Z2) 645010057017S 1
N7501 nsp 4P-PLUG B4P-VH 00MYP06003890 1
N7502 nsp B4B-EH-TS (LF)(SN) 4P RADIAL TAPING 00MYP0600391X 1
N7503 nsp B3B-EH-TS (LF)(SN) 3P RADIAL TAPING 00MYP0600383X 1
S7501,7502 00D2140209002 RELAY FTR-F1AD024V 00D2140209002 2
S7503 00D2140208003 RELAY(NA24W-K) 00D2140208003 1
V5901 0750100040030 RK27112MC 0750100040030 1 Ver.3
Z5902 nsp RETAINER 00M320J104010 1
Z7501-7508 nsp SPK CONTACTOR 00M04AJ123010 8
Z7509-7511 nsp STYLE PIN 00D2050452017 3
