Marantz PM8005 - Page 49

EXPLODED
EXPLODED
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The s
y
mbols in the column Remarks indicate the followin
g
destinations
U : North America model N : Euro
p
e model K : China model F : Ja
p
an mode
B : Black model SG : Silver
g
old mode
l
REF No. Part No. Part Name Remarks Q'ty New Ver
P1 nsp MAIN PWB UNIT 8U-110150-1 1 *
P2 nsp POWER STAGE PCB 8U-110150-2 1 *
★P3
nsp WIRE PROTECTION PWB UNIT 8U-110150-3 1 *
P4 nsp u-COM PCB 8U-110151-1 1 *
P5 nsp STANDBY LED PCB 8U-110151-2 1 *
P6 nsp INPUT SEL PCB 8U-110151-3 1 *
P7 nsp TONE PCB 8U-110151-4 1 *
P8 nsp HEADPHONE PCB 8U-110151-5 1 *
P9 nsp CLAMP PCB 8U-110151-6 1 *
P10 nsp POWER SW PCB 8U-110151-7 1 *
P11 nsp STANDBY PCB 8U-110151-8 1 *
P12 nsp PHONO AMP PCB 8U-110152-1 1 *
P13 nsp SPK TERMINAL PCB 8U-110152-2 1 *
P14 nsp VOLUME PCB 8U-110152-3 1 *
0010F 40241037801AM FRONT PANEL B 40241037801AM 1 *
0010F 40241037800AM FRONT PANEL SG 40241037800AM 1 *
0020F 421410006004M MARANTZ BADGE (AL) FOR M1 MODEL 421410006004M 1
0030F 42141003201AM BADGE (MARANTZ STAR) B 42141003201AM 1 *
0030F 42141003200AM BADGE (MARANTZ STAR) SG 42141003200AM 1 *
0050F 422410013005M ESCUTCHEON CENTER BASE BL PM7003 24AJ B 422410013005M 1
0050F 422410013036M ESCUTCHEON CENTER BASE SG PM7003 24AJ SG 422410013036M 1
0040F 422410012002M ESCUTCHEON CENTER PM7003 24AJ 422410012002M 1
0290F 481510004009M LENS IR BL PM7003 24AJ B 481510004009M 1
0290F 481510004047M LENS IR WH PM7003 24AJ SG 481510004047M 1
0060F 423410006000M LENS FUNCTION PM7003 24AJ 423410006000M 7
0070F 443410006103M FRONT CENTER MOLD BL PM7004 A334 B 443410006103M 1
0070F 443410006134M FRONT CENTER MOLD SG PM7004 A334 SG 443410006134M 1
0160F 402410034008M ESCUTCHEON R BL PM7003 24AJ B 402410034008M 1
0160F 402410034039M ESCUTCHEON R SG PM7003 24AJ SG 402410034039M 1
0080F 424510004006M RING VOLUME BL PM7003 24AJ B 424510004006M 2
0080F 424510004037M RING VOLUME SG PM7003 24AJ SG 424510004037M 2
0100F 40251037901AM ESCUTCHEON (L) N1B/U1B 40251037901AM 1 *
0100F 40251037902AM ESCUTCHEON (L) K1B 40251037902AM 1 *
0100F 40251037900AM ESCUTCHEON (L) SG 40251037900AM 1 *
0180F nsp STAY SA7003 33AK 442310004006M 1
0120F 481510003006M LENS 481510003006M 1
0300F 411510028006M BUTTON BL PM7003 24AJ B 411510028006M 4
0300F 411510028037M BUTTON SG PM7003 24AJ SG 411510028037M 4
★W0011
nsp PHR-PHR 2.0MMPICH 12PIN 14CM 0120102780010 1
★0330F
nsp WIRE CLAMPER 00M303V005010 1
★W0007
nsp 10P L=400 PH-PH UL1061 AWG28 61205058300AS 1 *
0130F 411510027003M BUTTON PUSH BL PM7003 24AJ B 411510027003M 1
0130F 411510027034M BUTTON PUSH SG PM7003 24AJ SG 411510027034M 1
★W0003
nsp VAR-VAR 7.92MMPICH 1PIN:BR.2PIN:BR22CM 120108950000 1
★WA001
nsp EHR3 EHR3 EHR4 CORD ASSY 614010001003M 1
0010H nsp MAIN HEATSINK 00M14AJ267010 1
0090H nsp BRACKET 00M14AJ160030 1
0020H nsp HEATSINK BRACKET 00M14AJ160010 2
! Q7013 nsp TRANSISTOR 2SA1303 (O P OR Y) PC=125W 00MHT113033A0 1
! Q7014 nsp TRANSISTOR 2SA1303 (O P OR Y) PC=125W 00MHT113033A0 1
! Q7011 nsp 2SC3284 (O P OR Y) PC=125W
00MHT332843A0 1
! Q7012 nsp 2SC3284 (O P OR Y) PC=125W 00MHT332843A0 1
0040H nsp STUD M3 9mm 45231001300AS 6
★W0008
nsp VHR-VHR(NTYPE)3.96MM 4PIN 19CM 612050091008M 1
0010R nsp REAR PANEL N 40631013600AM 1 *
0010R nsp REAR PANEL U 40631013602AM 1 *
0010R nsp REAR PANEL K 40631013603AM 1 *
0010R nsp REAR PANEL F 40631013601AM 1 *
0120R nsp SPEAKER PCB STUD 00M04AJ101010 2
J0002 nsp TERMINAL 00MYL03010330 1
J0003-J0006 646710024006M SPKT-1 RED 646710024006M 4
J0007-J0010 646710025009M SPKT-1 WHITE 646710025009M 4
0110R nsp SP SPACER 00M15AJ118023 8
0100R nsp SPEAKER NUT 00M04AJ011010 8
★0012R
nsp TOP COVER SHEET 00M14AJ107010 1
! J0001 00D2033996008 AC INLET (2P) 00D2033996008 1
★W0002
120109160060 VAR-NO CN7.92MMPICH1PIN:BR.2PIN:BL10CM 120109160060 1
0010C nsp CHASSIS 00M14AJ105014 1
0040C nsp BOTTOM LID PM8001(15AJ) 00M15AJ257013 2
0080C nsp FOOT 00M243W057310 4 *
0210C nsp CUSHION FOOT CHG1A360 00M32CW107010 4
0092C nsp 3 WASHER 0RD4751130005 4
0280C nsp BRACKET SA7003 33AK 444310036009M 2
★0270C
nsp WASHER 00M281K118010 2
0250C 442310006002M SIDE RETAINER R PM7003 24AJ 442310006002M 1
0230C nsp SIDE RETAINER L PM7003 24AJ 442310005009M 1
0180C nsp PHONO PCB BRACKET 00M14AJ160020 1
0020C nsp SCREW STOPPER 00M14AJ114010 1
0140C nsp PCB SUPPORT RICHICO 00M14AJ101010 1
★0011R
nsp TAPE PERMACEL PTFE FILM P-422 15MM X 33M 554010001002S 430
★W0005
nsp PH-PH 13PIN L=14CM 00MYA02131410 1
0300C nsp CONTACTOR PM7003 24AJ 488410003008M 1
★L0002
nsp GTFCK-16-8-13 FERRITECORE 11701001800AS 1
0220C nsp WIRE CLAMPER 453510024008M 1
! L0001 1010100030088 POWER TRANSFORMER 230V N/K 1010100030088 1
! L0001 101010024005M #POWER TRANSFORMER FOR 120V U 101010024005M 1
! L0001 1010100040018 POWER TRANSFORMER 100V F 1010100040018 1
0320F 00M14AJ107010 TOP COVER SHEET 00M14AJ107010 3
0010T 00M14AJ257320 TOP COVER BL PM7003 24AJ B 00M14AJ257320 1
0010T 00M14AJ257312 TOP COVER SG PM7003 24AJ SG 00M14AJ257312 1
0050T 436510015023M BUFFER TOP COVER INSIDE PM7003 24AJ 436510015023M 2
0035T 00M411K118012 SPACER 00M411K118012 1
0270F 41201011001AM KNOB AL ASSY B 41201011001AM 1 *
0270F 41201011000AM KNOB AL ASSY SG 41201011000AM 1 *
0280F 412410008006M KNOB AL CAP POINTER BL PM7003 24AJ B 412410008006M 1
