Marantz SR3000 - Electrical Partslist - Front Board

6-8 6-8
ELECTRICAL PARTSLIST - FRONT BOARD
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
MISCELLANEOUS
1400 N 4822 242 11033 CRYSTAL(4,332MH)
1403 4822 242 72066 CST8,00MT
1404 4822 276 13114 SWITCH, PUSH BUTTON
1406
4822 276 13114 SWITCH, PUSH BUTTON
1409
1410 4822 265 10981 15FE-BT-VK-N
1411
4822 276 13114 SWITCH, PUSH BUTTON
1416
1418 4822 276 13114 SWITCH, PUSH BUTTON
1419 4822 276 13114 SWITCH, PUSH BUTTON
1421 4822 273 10372 SWITCH, ROTARY
1422 4822 273 10372 SWITCH, ROTARY
1423 4822 273 10365 ROTARY ENCODER 24P
1424 4822 265 11584 1P YKB21-5209
1428 4822 265 11336 3P. FEM. CINCH
1429 4822 276 13114 SWITCH, PUSH BUTTON
1430 4822 276 13114 SWITCH, PUSH BUTTON
8002 4822 320 12706 FFC 15P - 220MM
CAPACITORS
2400 4822 124 41584 100UF 20% 10V
2402 N 5322 122 31647 1NF 10% X7R 63V
2403 3000 N 5322 116 80853 560PF 5% NP0 63V
2404 5322 122 31647 1NF 10% X7R 63V
2405 5322 122 32654 22NF 10% X7R 63V
2407 N 5322 122 34099 470PF 10% X7R 63V
2408 N 5322 122 32654 22NF 10% X7R 63V
2409 N 4822 124 22652 2,2UF 20% 50V
2410 N 5322 122 32654 22NF 10% X7R 63V
2412 4822 124 41751 47UF 20% 50V
2413 5322 122 32654 22NF 10% X7R 63V
2414 5322 122 32654 22NF 10% X7R 63V
2415 5322 122 32658 22PF 5% 50V
2416 5322 122 32658 22PF 5% 50V
2417 5322 122 32654 22NF 10% X7R 63V
2419 4000 5322 122 32654 22NF 10% X7R 63V
2420 4822 124 23432 100UF 20% 10V
2421 5322 122 32654 22NF 10% X7R 63V
2422 5322 122 32654 22NF 10% X7R 63V
2423
5322 122 32654 22NF 10% X7R 63V
2426
2427 5322 122 31647 1NF 10% X7R 63V
2428 4822 124 12032 4,7UF 20% 50V
2429 4822 124 41751 47UF 20% 50V
2430 4822 122 33575 220PF 5% NP0 63V CASE 0805
2431 4000 5322 122 32531 100PF 5% NP0 50V
2432 4000 5322 122 32531 100PF 5% NP0 50V
2433 5322 122 32531 100PF 5% NP0 50V
2434 4822 126 14076 220N 25V. P8020
2435
4822 122 33575 220PF 5% NP0 63V CASE 0805
2441
2442 N 4822 126 13692 47PF 1% NP0 63V
2443 N 4822 126 13692 47PF 1% NP0 63V
2444 5322 122 32654 22NF 10% X7R 63V
2445 5322 126 10223 4,7NF 10% X7R 63V
2447 5322 126 10223 4,7NF 10% X7R 63V
2448 5322 122 31647 1NF 10% X7R 63V
2449 5322 122 31647 1NF 10% X7R 63V
2454 5322 122 32654 22NF 10% X7R 63V
2455 4822 124 41751 47UF 20% 50V
2456 4822 124 40433 47UF 20% 25V
2457
5322 122 32654 22NF 10% X7R 63V
2461
2462 5322 122 31647 1NF 10% X7R 63V
2463
4000 5322 122 32531 100PF 5% NP0 50V
2466
2467
5322 122 32531 100PF 5% NP0 50V
2478
4000 N 5322 116 80853 560PF 5% NP0 63V
RESISTORS
3391 4822 051 10102 1K00 2% 0,25W
3392
4822 051 20223 22K00 5% 0,1W
3394
3395 4000 4822 051 20008 0R00 JUMP. (0805)
3396 3000 4822 051 10102 1K00 2% 0,25W
3400 4822 051 20479 47R00 5% 0,1W
3401 4822 050 21003 10K00 1% 0,6W
3402 4822 050 21003 10K00 1% 0,6W
3403 4822 117 11507 6K8 1% 0,1W
3404 4822 116 52219 330E 5% 0,5W
3405 4822 116 52257 22K 5% 0,5W
3406
4822 050 21003 10K00 1% 0,6W
3408
3409 4822 051 10102 1K00 2% 0,25W
3410 N 4822 117 11449 2K2 1% 0,1W
3411 N 4822 117 13579 220K 1% 0.1W RC12H 0805
3412 3000 4822 050 21003 10K00 1% 0,6W
3413 N 4822 050 11002 1K00 1% 0,4W
3414 4822 051 10102 1K00 2% 0,25W
3416 N 4822 117 10833 10K 1% 0,1W
3417
4822 117 10833 10K 1% 0,1W
3421
3422 N 4822 117 10833 10K 1% 0,1W
3424 4822 050 11002 1K00 1% 0,4W
3426 4822 050 11002 1K00 1% 0,4W
3427 4822 116 83868 150R 5% 0,5W
3430 4822 051 20223 22K00 5% 0,1W
3431 4822 117 10833 10K 1% 0,1W
3432 4822 052 10478 4R70 5% 0,33W
3434 4822 051 20223 22K00 5% 0,1W
3435 4822 116 52257 22K 5% 0,5W
3436 4822 116 52257 22K 5% 0,5W
3439 4822 117 10833 10K 1% 0,1W
3442 4822 117 10837 100K 1% 0.1W
3443 4822 116 52219 330E 5% 0,5W
3444 4822 116 52219 330E 5% 0,5W
3445 4000 4822 117 13577 330R 1% RC12H 0805 1,25W
3446 4000 4822 117 13577 330R 1% RC12H 0805 1,25W
3447 4822 116 52219 330E 5% 0,5W
3448 4000 4822 116 52219 330E 5% 0,5W
3449 4822 117 10837 100K 1% 0.1W
3451 4822 117 10833 10K 1% 0,1W
3452 4822 116 52219 330E 5% 0,5W
3453 4822 116 52219 330E 5% 0,5W
3454 3000 4822 051 20008 0R00 JUMP. (0805)
3455 U, K 4822 051 20223 22K00 5% 0,1W
3457 4822 116 52219 330E 5% 0,5W
3458 4822 117 13577 330R 1% RC12H 0805 1,25W
3459
4822 117 10833 10K 1% 0,1W
3464
3465
4822 117 11503 220R 1% 0.1W
3470
3471 4822 051 10102 1K00 2% 0,25W
3472 4822 051 10102 1K00 2% 0,25W
3473 4822 051 20008 0R00 JUMP. (0805)
3474 4822 051 20008 0R00 JUMP. (0805)
3475 4822 117 10837 100K 1% 0.1W
3476 4822 117 10837 100K 1% 0.1W
3477 4822 117 12521 68R 1% 0,1W
3478 4000 4822 117 10837 100K 1% 0.1W
3479 4000 4822 051 10102 1K00 2% 0,25W
3480 4000 4822 117 10837 100K 1% 0.1W
3481 4000 4822 051 10102 1K00 2% 0,25W
3482 4822 117 10837 100K 1% 0.1W
3483 3000 4822 117 10837 100K 1% 0.1W
3484 4000 4822 051 10102 1K00 2% 0,25W
3485 4000 4822 051 20008 0R00 JUMP. (0805)
3486 4822 051 20472 4K70 5% 0,1W
3487 4822 117 10833 10K 1% 0,1W
3488 3000 4822 050 24708 4R70 1% 0,6W
3489 3000 4822 050 24708 4R70 1% 0,6W
3490 3000 4822 051 20008 0R00 JUMP. (0805)
3492 4822 117 10837 100K 1% 0.1W
3493
4822 051 20471 470R00 5% 0,1W
3501
3502 4000 4822 051 10102 1K00 2% 0,25W
3751 4000
4822 051 20333 33K00 5% 0,1W
3754 4000
3755
4822 051 20333 33K00 5% 0,1W
3781
4401
4822 051 20008 0R00 JUMP. (0805)
4404
4406
4822 051 20008 0R00 JUMP. (0805)
4408
4410 4822 051 20008 0R00 JUMP. (0805)
4411 4822 051 20008 0R00 JUMP. (0805)
4413 4822 051 20008 0R00 JUMP. (0805)
4416
4822 051 20008 0R00 JUMP. (0805)
4426
4450 4822 051 20008 0R00 JUMP. (0805)
FILTERS
5400 N 4822 157 11477 LAL02TB2R2J
5401 4822 157 11477 LAL02TB2R2J
5402 4000 4822 157 11477 LAL02TB2R2J
5403 4822 157 11477 LAL02TB2R2J
DIODES
6400 9322 100 14682 LTL1214A
6403
4822 130 30621 1N4148
6406
6407
4000 4822 130 82978 LTL-16KPE-P
6409
6410 4822 130 82978 LTL-16KPE-P
6411 3000 4822 130 30621 1N4148
6412 4000 4822 130 82978 LTL-16KPE-P
6413 4000 4822 130 82978 LTL-16KPE-P
6414 4822 130 30621 1N4148
6415
4000 4822 130 82978 LTL-16KPE-P
6418
6419 4822 130 30621 1N4148
6420 4822 130 30621 1N4148
6422 4822 130 82978 LTL-16KPE-P
6423 4822 130 82978 LTL-16KPE-P
6424 4822 130 83757 BAS216
TRNSISTORS & ICs
7402 4822 130 11607 PDTA144ET
7403 4822 130 10165 GP1U28XP
7404 N 4822 209 31981 SAA6579T
7405 4822 209 17445 M24C08-MN6
7409 4822 130 60511 BC847B
7411 4000 5322 209 11306 HEF4094BT
7412 5322 209 11306 HEF4094BT
7413 4000 2722 171 07179 16-BT-68GK
7414 3000 2722 171 07178 12-BT-113GK
7415 3000 4822 209 17446 TMP87CS71F/FR755.1
7415 4000 3103 308 83880 TMP87CS71F/SR4000
7416 4000 4822 130 60511 BC847B
7417 4822 130 60511 BC847B
7418 4000 4822 130 60511 BC847B
7419 9340 310 30215 PDTC144ET
7421 4822 130 11607 PDTA144ET
