13-1
MECHANICAL PARTSLIST - EXPLODED VIEW
Note:
Only the parts mentioned in this list are normal service parts.
nsp = Part is listed for reference only. MARANTZ will NOT
supply these parts.
13-1
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO
COLOR
0001 3000 U 3103 307 97730 FRONT CAB ASSY SR3000/U
0001 3000 N 3103 307 97690 FRONT CAB ASSY SR3000/N
0001 4000 U, K 3103 307 97740 FRONT CAB ASSY SR4000
(BLACK)
/U, /K BLACK
0001 4000 K 3103 307 98120 FRONT CAB ASSY SR4000
(GOLD) /K GOLD
0001 4000 N 3103 307 97710 FRONT CAB ASSY SR4000/N
0002 BLACK 3103 304 67030 BUTTON-SURROUND
0002 GOLD 3103 307 98100 BUTTON-SURROUND GOLD
0003 BLACK 3103 304 67040 BUTTON-TUNER
0003 GOLD 3103 307 98110 BUTTON-TUNER GOLD
0004 BLACK 3103 304 67020 BUTTON-MENU
0004 GOLD 3103 307 98090 BUTTON-MENU GOLD
0005 BLACK 3103 304 67010 BUTTON-BASS TREBLE
0005 GOLD 3103 307 98080 BUTTON-BASS TREBLE GOLD
0008 3103 304 67070 LIGHT-GUIDE-SURROUND
0009 4000 3103 304 67080 LIGHT-GUIDE-VIRTUAL-HALL
0010 3000 3103 304 67120 LIGHT-GUIDE-SELECTOR-6CH
0010 4000 3103 304 67060 LIGHT-GUIDE-SELECTOR
0013 3000 3103 307 97700 RING-KNOB-SOURCE-SEL-PRI
0013 4000 BLACK 3103 307 97720 RING-KNOB-SOURCE-SEL-PRI
0013 4000 GOLD 3103 307 98160 RING-KNOB-SOURCE-SEL-PRI
GOLD
0014 3103 304 67110 WINDOW-DISPLAY
0025 BLACK 3103 304 07010 KNOB-VOLUME
0025 GOLD 3103 307 98150 KNOB-VOLUME GOLD
0026 BLACK 3103 304 07000 KNOB-SOURCE-SEL
0026 GOLD 3103 307 98140 KNOB-SOURCE-SEL GOLD
0027 BLACK 3103 304 06990 KNOB-MENU-NAV
0027 GOLD 3103 307 98130 KNOB-MENU-NAV GOLD
0028 4822 454 11825 BADGE MARANTZ
0029 4822 492 51374 SPRING
0036 4822 462 42129 FOOT GOLD
0038 3103 307 97870 LEG GOLD MARANTZ
0094 4822 466 93148 SPACER STEEL
0115 3103 304 67100 POWER-ROD
0116 BLACK 4822 410 12499 BUTTON POWER
0116 GOLD 3103 307 99120 BUTTON POWER GOLD
0117 4822 532 60948 BUSH PLASTIC
0125 BLACK
nsp COVERPLATE
0125 GOLD
nsp COVERPLATE GOLD
0350 U 4822 320 11094 FM AERIAL 300R
0350 N, K 4822 303 50063 FM AERIAL 75R
0352 4822 303 50082 AM FRAME AERIAL
0356 3000 3139 228 84030 IRT ASSY RC2537/02 PACKED
0356 4000 3104 219 03910 IRT ASSY PACKED
0358 K 4822 263 21092 ADAPTER PLUG
0387 3000 U 3104 215 36170 USER GUIDE SR3000/U
0387 3000 N 3104 215 36150 USER GUIDE SR3000/N
0387 4000 U 3104 215 36180 USER GUIDE SR4000/U
0387 4000 N 3104 215 36160 USER GUIDE SR4000/N
0387 4000 K 3104 215 36190 USER GUIDE SR4000/K
1003 4000 3104 217 05750 MULTI CHANNEL DECODING
MODULE
5001 3000 U 3103 308 30240 MAINS TRAFO SR3000/U
5001 3000 N 3103 308 30370 MAINS TRAFO SR3000/N
5001 4000 U 4822 146 21225 MAINS TRAFO SR4000/U
5001 4000 N 4822 146 11165 MAINS TRAFO SR4000/N
5001 4000 K 4822 146 11169 MAINS TRAFO SR4000/K
8002 4822 320 12706 FFC 15P - 220MM
8020 N, K 4822 321 11139 MAINS CORD
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO
COLOR
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO
COLOR
0026 4822 492 11068 SPRING
MISCELLANEOUS
1258 3000 4822 071 51602 19372(1.6A)
1304 3000 2422 015 19011
CON BM CLICK H 6P F 3*RDBK B
1306 4000 2422 015 19189
CON BM SCREW H 6P F RDBK B
1502
4822 267 31823 YKC21-3424
1514
1516 4000 4822 267 31823 YKC21-3424
1520 4822 265 10981 15FE-BT-VK-N
1521 4000 2422 025 11067 CON BM V 12P F 2.50
1523
1530 4000 4822 071 53151 19372(315MA)
1541 4822 267 41009 MTZJ2.0B
1542 4822 267 31448 CONNECTOR
1550 4822 267 31729 CONNECTOR
1801 4822 267 31996 CONN. 1P
1802 4822 265 11619 CINCH 2P
1803 4822 265 11619 CINCH 2P
1901 4822 265 10967 YKD21-0185
CAPACITORS
2251 5322 121 42578 100NF 5% 250V
2252 3000 4822 121 43526 47NF 5% 250V
2253 4000 4822 121 43526 47NF 5% 250V
2254 5322 121 42578 100NF 5% 250V
2255 3000 4822 121 43526 47NF 5% 250V
2256 4000 4822 121 43526 47NF 5% 250V
2258 3000 4822 124 42367 3300UF 20% 35V
2259 4000 4822 124 80415 4700UF 20% 50V
2260 4000 4822 124 80415 4700UF 20% 50V
2261 3000 4822 124 42367 3300UF 20% 35V
2263 3000 4822 124 80415 4700UF 20% 50V
2265 3000 4822 124 80415 4700UF 20% 50V
2266 5322 121 42386 100NF 5% 63V
2268 5322 121 42386 100NF 5% 63V
2269 4822 124 11583 2200UF 20% 35V
2270 4822 126 13838 100NF Y5V 0805 50V P80M20
2271 4822 126 14583 470NF 10% 16V XTR 0805
2272 4000 4822 124 12328 6800UF 16V
2273 4822 126 14585 100NF 10% X7R 0805 50V
2274 4822 126 14583 470NF 10% 16V XTR 0805
2275 4822 124 81144 1000U 16V
2276 4822 126 14585 100NF 10% X7R 0805 50V
2277 4822 126 14583 470NF 10% 16V XTR 0805
2278 4822 124 21913 1UF 20% 63V
2280 4822 124 41584 100UF 20% 10V
2281 4822 126 13838 100NF Y5V 0805 50V P80M20
2282 4822 126 14583 470NF 10% 16V XTR 0805
2283 3000 4822 124 11769 220UF 20% 50V
2287 3000 4822 124 40784 3300UF 20% 16V
2290 4822 124 40248 10UF 20% 63V
2292 4000 4822 124 12132 6800UF 20% LA5 63V
2293 4000 4822 124 12132 6800UF 20% LA5 63V
2295 4822 122 33177 10NF 20% X7R 50V
2297 3000 4822 124 40248 10UF 20% 63V
2298 3000 4822 126 13751 47NF 10% X7R 63V
2298 4000 5322 122 32654 22NF 10% X7R 63V
2299 4000 5322 124 40641 10UF 20% 100V
2301 5322 122 32654 22NF 10% X7R 63V
2302 3000 4822 124 81151 22UF 50V
2303 4000 4822 124 40764 22UF 100V
2305 4000 5322 124 40641 10UF 20% 100V
2306 4822 124 40248 10UF 20% 63V
2307 3000 5322 122 32287 4,7PF 5% NP0 50V
2308 4000 5322 122 32448 10PF 5% NP0 63V CASE 0805
2309 4000 5322 122 32448 10PF 5% NP0 63V CASE 0805
2310 4822 124 22652 2,2UF 20% 50V
2311 5322 122 32268 470PF 10% 50V
2313 4822 122 33575 220PF 5% NP0 63V CASE 0805
2314 4822 126 13473 220NF 80-20% 50V
2315 4822 124 81151 22UF 50V
2316 4822 124 22652 2,2UF 20% 50V
2317 3000 5322 126 10223 4,7NF 10% X7R 63V
2319 5322 122 32268 470PF 10% 50V
2321 4822 126 13473 220NF 80-20% 50V
2322 3000 5322 122 32531 100PF 5%NP0 50V
2324 3000 5322 122 32287 4,7PF 5% NP0 50V
2325 4822 122 33575 220PF 5% NP0 63V CASE 0805
2326 4000 5322 122 32448 10PF 5% NP0 63V CASE 0805
2327 4000 5322 122 32448 10PF 5% NP0 63V CASE 0805
2328 3000 5322 126 10223 4,7NF 10% X7R 63V
2330 4822 124 81151 22UF 50V
2331 3000 5322 122 32531 100PF 5% NP0 50V
2333 4822 126 13473 220NF 80-20% 50V
2334 4822 124 22652 2,2UF 20% 50V
2335 3000 5322 126 10223 4,7NF 10% X7R 63V
2337 5322 122 32268 470PF 10% 50V
2339 3000 5322 122 32531 100PF 5% NP0 50V
2341 4822 122 33575 220PF 5% NP0 63V CASE 0805
2345 4000 5322 122 32448 10PF 5% NP0 63V CASE 0805
2346 4822 124 81151 22UF 50V
2347 3000 5322 122 32287 4,7PF 5% NP0 50V
2348 4000 5322 122 32448 10PF 5% NP0 63V CASE 0805
2349 4822 124 40248 10UF 20% 63V
2350 4822 124 40181 220UF 20% 10V
2351 3000 4822 126 13751 47NF 10% X7R 63V
2352 3000 4822 124 81151 22UF 50V
2353 4000 4822 124 40764 22UF 100V
2354 4000 5322 124 40641 10UF 20% 100V
2357 4822 126 12882 100NF +80-20% 50V
2358
4822 126 13473 220NF 80-20% 50V
2360
2365 4822 121 41857 10NF 5% 250V
2371
4000 5322 126 10223 4,7NF 10% X7R 63V
2373
2374
4000 5322 122 32531 100PF 5% NP0 50V
2376
2501 5322 126 10511 1NF 5% NP0 50V
2502 5322 126 10511 1NF 5% NP0 50V
2505
5322 126 10511 1NF 5% NP0 50V
2507
2508 5322 122 32531 100PF 5% NP0 50V
2509 5322 122 32531 100PF 5% NP0 50V
2510 4000 5322 122 32531 100PF 5% NP0 50V
2511
5322 122 32531 100PF 5% NP0 50V
2524
2525 4000 5322 122 32531 100PF 5% NP0 50V
2526 4000 5322 122 32531 100PF 5% NP0 50V
2527 4000 4822 124 41751 47UF 20% 50V
2528 4000 4822 124 41751 47UF 20% 50V
2529 4000 4822 126 13838 100NF Y5V 0805 50V P80M20
2530 4000 4822 126 13838 100NF Y5V 0805 50V P80M20
2531 4822 121 42408 220NF 5% 63V
2532 4822 121 42408 220NF 5% 63V
2533
4822 124 40248 10UF 20% 63V
2538
2539 4822 124 40207 100UF 20% 25V
2540 4822 124 40433 47UF 20% 25V
2541 4822 124 40248 10UF 20% 63V
2542 4822 124 40248 10UF 20% 63V
2543 4822 124 41584 100UF 20% 10V
2544 4822 124 41584 100UF 20% 10V
2545 5322 122 32531 100PF 5% NP0 50V
2546 5322 122 32531 100PF 5% NP0 50V
2549 5322 122 32658 22PF 5% 50V
2550 5322 122 32658 22PF 5% 50V
2551 4822 126 13838 100NF Y5V 0805 50V P80M20
2552 4822 126 13838 100NF Y5V 0805 50V P80M20
2553 4822 124 41751 47UF 20% 50V
2554 4822 124 41751 47UF 20% 50V
2555 4822 126 13838 100NF Y5V 0805 50V P80M20
2556 4822 126 13838 100NF Y5V 0805 50V P80M20
2557 4822 124 41751 47UF 20% 50V
2558 4822 124 41751 47UF 20% 50V
2559 4822 126 12105 CER2 0805 X7R 50V 33NF PM5
2561 4000 4822 124 40764 22UF 100V
2562 4000
4822 124 40764 22UF 100V
2563 4822 123 14025 16V 2200U 20%
2564
4822 124 22652 2,2UF 20% 50V
2566
2567 4822 124 40769 4,7UF 20% 100V
2568 4822 124 40769 4,7UF 20% 100V
2569 5322 122 32531 100PF 5% NP0 50V
2570 4000 5322 122 32531 100PF 5% NP0 50V
2571 4000 4822 124 40248 10UF 20% 63V
2572 4000 4822 124 40248 10UF 20% 63V
2573 4000 5322 122 33538 150PF 2% NP0 63V
2574 4000 5322 122 33538 150PF 2% NP0 63V
2575 4000 4822 124 40248 10UF 20% 63V
2576 4000 4822 124 40248 10UF 20% 63V
2577 4000 4822 122 33177 10NF 20% X7R 50V
2578 4000 4822 122 33177 10NF 20% X7R 50V
2579 4000 4822 122 33127 2,2NF 10% X7R 63V
2580 4000 4822 122 33127 2,2NF 10% X7R 63V
2581 4000 4822 124 41751 47UF 20% 50V
2582 4000 4822 124 41751 47UF 20% 50V
2583 4000 2222 861 15272 CER1 0805 NP0 50V
2584 4000 2222 861 15272 CER1 0805 NP0 50V
2585 4000 4822 126 13695 82PF 1% NP0 63V
2586 4000 4822 126 13695 82PF 1% NP0 63V
2593 4000 4822 124 81151 22UF 50V
2594 4000 4822 124 81151 22UF 50V
2595 4000 5322 122 32531 100PF 5% NP0 50V
2596 4000 5322 122 32531 100PF 5% NP0 50V
2599 4000 5322 122 32658 22PF 5% 50V
2600 4000 5322 122 32658 22PF 5% 50V
2603 4822 124 81151 22UF 50V
2604 4822 124 81151 22UF 50V
2605 4822 126 13692 47PF 1% NP0 63V
2606 4822 126 13692 47PF 1% NP0 63V
2607 4822 124 41751 47UF 20% 50V
2608 4822 124 41751 47UF 20% 50V
2609 4822 122 33575 220PF 5% NP0 63V CASE 0805
2610 4822 122 33575 220PF 5% NP0 63V CASE 0805
2611 4822 124 40207 100UF 20% 25V
2612 4822 124 40248 10UF 20% 63V
2613 4822 124 40248 10UF 20% 63V
2614 4822 124 40207 100UF 20% 25V
2615 5322 122 32654 22NF 10% X7R 63V
2616 5322 122 32654 22NF 10% X7R 63V
2617 4822 124 40248 10UF 20% 63V
2618 4822 124 40248 10UF 20% 63V
2619 5322 122 32531 100PF 5% NP0 50V
2620 5322 122 32531 100PF 5% NP0 50V
2622
5322 122 32531 100PF 5% NP0 50V
2624
2625
4000 5322 122 32531 100PF 5% NP0 50V
2627
2628 4822 126 14585 100NF 10% X7R 0805 50V
2629 4822 124 41751 47UF 20% 50V
2630
5322 121 42386 100NF 5% 63V
2632
2633
5322 122 32654 22NF 10% X7R 63V
2635
2636 4822 126 14585 100NF 10% X7R 0805 50V
2637 4822 124 41751 47UF 20% 50V
2638 4822 126 14585 100NF 10% X7R 0805 50V
2639 4822 124 41751 47UF 20% 50V
2641 4822 124 21913 1UF 20% 63V
ELECTRICAL PARTSLIST - MONO BOARD
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO
COLOR
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO
COLOR
