Marantz SR3000 - Electrical Parts List

7B-5
MISCELLANEOUS
1101 4822 267 31505
SOCKET 2-POLE CLICKFIT, 300Ω only for /17
1102 4822 267 10283 SOCKET COAX, IEC 75Ω not for /17
CAPACITORS
2101 © 5322 122 32531 100pF 5% 50V
not for /17
2101 © 5322 122 32452 47pF 5% 63V only for /17
2102 © 4822 122 33177 10nF 20% 50V
2103 © 5322 122 34123 1nF 10% 50V
2104 4822 122 33195 100pF 10% 50V
2106 4822 125 60101 3-11pF TRIMCAP.
2107 4822 121 51319 1µF 20% 50V
2120 © 5322 122 32658 22pF 5% 50V
2125 4822 121 51381 560pF 1% 400V
2126 © 5322 122 31863 330pF 5% 50V
2127 © 4822 126 13473 220nF 20% 50V
2128 4822 124 41579 10µF 20% 50V
2129 4822 124 41584 100µF 20% 10V
2130 4822 126 11585 22nF 20% 50V
2131 © 4822 126 13482 470nF 20% 16V
2132 © 4822 126 13482 470nF 20% 16V
2133 4822 124 40242 1µF 20% 63V
2134 © 4822 126 13188 15nF 5% 63V
not for /17
2134 © 5322 122 32654 22nF 10% 63V only for /17
2135 4822 124 40746 0,22µF 20% 63V
2136 © 4822 126 13188 15nF 5% 63V
not for /17
2136 © 5322 122 32654 22nF 10% 63V only for /17
2137 4822 124 40746 0,22µF 20% 63V
2138 4822 124 41576 2,2µF 20% 50V
2139 © 4822 126 14236 15pF 5% 50V
2141 © 4822 126 10002 100nF 20% 50V
2142 © 4822 126 10002 100nF 20% 50V
2143 © 4822 126 13473 220nF 20% 50V
2144 4822 124 40242 1µF 20% 63V
2145 © 4822 122 33575 220pF 5% 50V
2146 © 4822 122 33575 220pF 5% 50V
2147 © 4822 122 33575 220pF 5% 50V
2148 4822 126 11585 22nF 20% 50V
2149 © 5322 122 32654 22nF 10% 63V
2150 © 4822 122 31947 100nF 20% 50V
2152 © 4822 126 12105 33nF 5% 63V
not for /14
2152 © 5322 116 80853 560pF 5% 63V only for /14
2153 © 4822 122 32139 12pF 5% 63V only for /14
2153 © 4822 122 32504 15pF 5% 50V not for /14
2155 4822 125 60101 3-11pF TRIMCAP.
2159 © 5322 122 32659 33pF 5% 50V
2160 © 5322 122 32654 22nF 10% 63V
2164 © 4822 126 13482 470nF 20% 16V
2165 © 4822 126 10002 100nF 20% 50V
2166 © 5322 122 34123 1nF 10% 50V
2167 © 4822 122 32139 12pF 5% 63V
2168 © 4822 126 13695 82pF 1% 63V
RESISTORS
3101 © 4822 051 20333 33kΩ 5% 0,1W
not for /14
3101 © 4822 051 20562 5,6kΩ 5% 0,1W only for /14
3102 © 4822 051 20104 100kΩ 5% 0,1W
3103 © 4822 117 10965 18kΩ 2% 0,1W
3104 © 4822 117 11448 180Ω 10% 0,1W
3105 4822 116 83872 220Ω 5% 0,5W
3110 4822 116 52195 47Ω 5% 0,5W
3120 © 4822 051 20008 CHIP JUMPER 0805
3132 4822 116 52195 47Ω 5% 0,5W
3134 © 4822 051 20224 220kΩ 5% 0,1W
3141 © 4822 117 11148 56kΩ 1% 0,1W
RESISTORS
3142 4822 100 11163 100kΩ TRIMPOT LIN.
3145 © 4822 117 11449 2,2kΩ 1% 0,1W
3146 © 4822 051 20229 22Ω 5% 0,1W
3152 4822 116 83883 470Ω 5% 0,16W
3153 © 4822 051 20471 470Ω 5% 0,1W
3154 4822 116 83868 150Ω 5% 0,5W
3155 © 4822 051 20471 470Ω 5% 0,1W
3156 © 4822 051 20104 100kΩ 5% 0,1W
not for /14/17
3157 4822 116 52234 100kΩ 5% 0,5W only for /14
3158 4822 116 83883 470Ω 5% 0,16W
3159 4822 116 83883 470Ω 5% 0,16W
3160 4822 116 83883 470Ω 5% 0,16W
3161 4822 116 83883 470Ω 5% 0,16W
3167 © 4822 117 11503 220Ω 5% 0,1W
3169 © 4822 051 20154 150kΩ 5% 0,1W
3170 4822 116 52234 100kΩ 5% 0,5W
not for /14
3171 4822 116 52219 330Ω 5% 0,5W
4101 © 4822 051 20008 CHIP JUMPER 0805
4102 © 4822 051 20008 CHIP JUMPER 0805
4103 © 4822 051 20008 CHIP JUMPER 0805
4104 © 4822 051 20008 CHIP JUMPER 0805
4105 © 4822 051 20008 CHIP JUMPER 0805
4106 © 4822 051 20008 CHIP JUMPER 0805
4108 © 4822 051 20008 CHIP JUMPER 0805
4111 © 4822 051 20008 CHIP JUMPER 0805
4120 © 4822 051 20008 CHIP JUMPER 0805
4150 © 4822 051 10008 CHIP JUMPER 1206
4152 © 4822 051 10008 CHIP JUMPER 1206
4153 © 4822 051 10008 CHIP JUMPER 1206
4154 © 4822 051 10008 CHIP JUMPER 1206
4157 © 4822 051 10008 CHIP JUMPER 1206
4158 © 4822 051 10008 CHIP JUMPER 1206
4159 © 4822 051 10008 CHIP JUMPER 1206
COILS
5102 4822 157 71634 RF-COIL MW
5109 4822 242 70665 FM-IF FILTER 10,7MHZ
5110 4822 242 70665 FM-IF FILTER 10,7MHZ
5111 4822 158 60511 AM-IF FILTER 450kHz
5112 4822 157 70302 AM-IF FILTER 450kHz
5114 4822 157 70302 AM-IF FILTER 450kHz
5119 4822 157 11443 DISCRIMINATOR COIL
5121 4822 242 10261 QUARTZ 75kHz
5123 4822 157 60517 RF-COIL AM
5130 4822 156 30947 RF COIL 1,5 TURNS
5131 4822 156 30947 RF COIL 1,5 TURNS
DIODES
6103 4822 130 30621 1N4148
6104 4822 130 30621 1N4148
6105 © 4822 130 83075 HN1V02H
6106 4822 130 30621 1N4148
6107 4822 130 34488 BZX79-C11
6120 4822 130 30621 1N4148
only for /14/17
6130 © 4822 130 82833 1SV228
6131 © 4822 130 82833 1SV228
TRANSISTORS
7102 4822 130 60093 2SA838B
7111 © 5322 130 42136 BC848C
INTEGRATED CIRCUITS
7101 © 4822 209 90924 TEA5757H/V1, RADIO IC
ELECTRICAL PARTSLIST TUNER ECO5
