Marantz SR3000 - Electrical Partslist - Mains Board

10-5
ELECTRICAL PARTSLIST - MAINS BOARD
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
MISCELLANEOUS
1051 N, K 4822 267 31994 MAINS OUTLET
1052 3000 U 4822 265 11605 CCT1302-0202 MAINS LET
1053 4000 N, K 4822 267 31994 MAINS OUTLET
1054 4000 U 2422 030 00301 MAINS OUTLET
1055 4000 K 4822 272 10269 VOLTAGE SEL.
1056 4822 276 13224 MAINS SWITCH
1061 4822 265 20723 MAINS INLET
1062 4822 280 10391 RELAY
1063 4000 K 4822 267 10728 B4P7-VH
1064 4822 265 20723 B2P3-VH
1065 4000 K 4822 071 54002 19372 (4A)
1066 3000 U 4822 253 10126 19374 (4,0A)
1066 4000 U 4822 252 51123 19374A1 (6,3A)
1066 4000 K 4822 071 54002 19372 (4A)
1067 N 2422 086 10912 FUSE 5X20 ET 2,50A 250V IEC B
1067 4000 K 2422 086 10915 FUSE 5X20 ET 5,00A 250V IEC B
1068 4000 K 4822 071 52001 19372 (200MA)
1069 U, N 4822 071 53151 19372 (315MA)
1078 4822 071 51602 19372 (1.6A)
1079 4822 071 52002 19372 (2A)
1081
4822 071 55002 19372 (5A)
1084
CAPACITORS
2051
4822 121 43526 47NF 5% 250V
2052
2053
4000 K 4822 124 40207 100UF 20% 25V
2054
2055 4822 126 14084 4,7NF 20% 250V
RESISTORS
3051 U 4822 053 21106 10M00 5% 0,5W
3052
4822 050 11002 1K00 1% 0,4W
3053
3054 4000 K 4822 116 52283 4K7 5% 0,5W
3055 4000 K 4822 116 52256 2K2 5% 0,5W
3056 4000 K 4822 050 21003 10K00 1% 0,6W
3057 4822 116 52179 12E 5% 0,5W
3058 4822 116 52256 2K2 5% 0,5W
3079 4000 K 4822 052 10108 1R00 5% 0,33W
TRAFO
5052 U 4822 146 11142 STBY TRAFO for U
5052 N 4822 146 11143 STBY TRAFO for N
5052 4000 K 4822 146 11144 STBY TRAFO for K
DIODES
6051 4822 130 30621 1N4148
6052
4822 130 31878 1N4003G
6056
6057
4822 130 30621 1N4148
6058
6059
4000 K 4822 130 31878 1N4003G
6060
6061 4000 K 4822 130 34382 BZX79-B8V2
6062
4822 130 30621 1N4148
6064
6065 4000 K 4822 130 31878 1N4003G
TRANSISTORS
7051 4000 K 4822 130 41246 BC327-25
7052 4000 K 4822 130 40959 BC547B
7053 4822 130 40981 BC337-25
