Marantz SR3000 - Electrical Partslist - Dolby Prologic Board

8-7
ELECTRICAL PARTSLIST - DOLBY PROLOGIC BOARD
MISCELLANEOUS
1003 4822 214 13051 DPL MODULE
2701 4822 124 41579 10UF 20% 50V
2702 4822 124 41579 10UF 20% 50V
2703 4822 124 41579 10UF 20% 50V
2704 4822 124 41579 10UF 20% 50V
2705 4822 124 41579 10UF 20% 50V
2706 4822 124 41579 10UF 20% 50V
2707 4822 124 41584 100UF 20% 10V
2708 4822 124 41584 100UF 20% 10V
2709 4822 124 41584 100UF 20% 10V
2710 4822 124 11912 220UF 20% 6,3V
2711 4822 124 41579 10UF 20% 50V
2712 4822 124 40433 47UF20% 25V
2713 4822 126 13196 100NF 10% 0805 X7R 2
2714 5322 121 42386 100NF 5% 63V
2715 4822 126 13196 100NF 10% 0805 X7R 2
2716 4822 126 13196 100NF 10% 0805 X7R 2
2717 4822 124 81151 22UF 50V
2718 5322 122 32531 100PF 5%NP0 50V
2719 5322 122 32531 100PF 5%NP0 50V
2720 5322 122 32531 100PF 5%NP0 50V
2723 4822 124 40242 1UF20% 63V
2724 4822 122 33177 10NF 20% X7R 50V
2725 4822 126 10847 1,8NF10%X7R 63V
2726 5322 121 42465 68NF 5% 63V
2727 5322 121 42386 100NF 5% 63V
2728 5322 121 42386 100NF 5% 63V
2729 5322 121 42465 68NF 5% 63V
2730 4822 122 33177 10NF 20% X7R 50V
2731 4822 126 10847 1,8NF10%X7R 63V
2732 4822 126 13196 100NF 10% 0805 X7R 2
2733 5322 121 42386 100NF 5% 63V
2734 4822 126 10847 1,8NF10%X7R 63V
2735 4822 126 13196 100NF 10% 0805 X7R 2
2736 4822 122 33575 220PF 5%NPO 50V
2737 4822 122 32646 5,6NF10%X7R 50V
2738 4822 122 33797 47NF20%Y5V 50V
2739 4822 121 42408 220NF 5% 63V
2740 4822 121 42408 220NF 5% 63V
2741 4822 124 40769 4,7UF20% 100V
2742 4822 124 40769 4,7UF20% 100V
2743 4822 121 42408 220NF 5% 63V
2744 4822 121 42408 220NF 5% 63V
2745 4822 126 13196 100NF 10% 0805 X7R 2
2746 4822 121 43526 47NF 5% 250V
2747 4822 121 43526 47NF 5% 250V
2748 5322 121 42386 100NF 5% 63V
2749 4822 126 13196 100NF 10% 0805 X7R 2
2750 5322 122 32654 22NF10%X7R 63V
2751 5322 122 32654 22NF10%X7R 63V
2752 4822 126 13196 100NF 10% 0805 X7R 2
2753 4822 122 32535 680PF10%X7R 63V
2754 5322 126 10184 680P 5% NPO 50V.
2755 5322 121 42386 100NF 5% 63V
2756 5322 121 42386 100NF 5% 63V
2757 5322 121 42386 100NF 5% 63V
2758 5322 121 42386 100NF 5% 63V
2759 4822 124 81151 22UF 50V
2760 4822 124 40242 1UF20% 63V
2761 4822 122 32646 5,6NF10%X7R 50V
2762 5322 122 32268 470PF 10% 50V
2763 5322 122 32268 470PF 10% 50V
2780 5322 121 42661 330NF 5% 63V
2781 5322 122 32658 22PF 5% 50V
2783 5322 122 32658 22PF 5% 50V
2785 4822 126 13196 100NF 10% 0805 X7R 2
2788 4822 124 41579 10UF 20% 50V
2789 4822 124 41579 10UF 20% 50V
3701 4822 051 20104 100K00 5% 0,1W
3702 4822 051 20104 100K00 5% 0,1W
3703 4822 051 20104 100K00 5% 0,1W
3704 4822 051 20104 100K00 5% 0,1W
3705 4822 051 20104 100K00 5% 0,1W
3706 4822 051 20104 100K00 5% 0,1W
3709 4822 051 20104 100K00 5% 0,1W
3710 4822 117 13579 220K 1% 0.1W RC12H 0
3712 4822 051 20475 4M70 5% 0,1W
3714 4822 117 10833 10K 1% 0,1W
3715 4822 117 10833 10K 1% 0,1W
3716 4822 051 20105 1M00 5% 0,1W
3718 4822 051 10102 1K00 2% 0,25W
3719 4822 051 10102 1K00 2% 0,25W
3720 4822 051 10102 1K00 2% 0,25W
3727 4822 117 10834 47K 1% 0,1W
3728 4822 051 20184 180K00 5% 0,1W
3733 4822 117 11383 12K 1% 0,1W
3734 4822 117 11383 12K 1% 0,1W
3735 4822 117 11383 12K 1% 0,1W
3736 4822 117 11383 12K 1% 0,1W
3737 4822 051 20334 330K00 5% 0,1W
3739 4822 117 10834 47K 1% 0,1W
3740 4822 051 20153 15K00 5% 0,1W
3741 4822 117 10834 47K 1% 0,1W
3742 4822 051 20153 15K00 5% 0,1W
3743 4822 117 11507 6K8 1% 0,1W
3744 4822 051 20681 680R00 5% 0,1W
3745 4822 117 11507 6K8 1% 0,1W
3746 4822 051 20681 680R00 5% 0,1W
3747 4822 051 20471 470R00 5% 0,1W
3748 4822 051 20471 470R00 5% 0,1W
3780 4822 117 10833 10K 1% 0,1W
3781 4822 117 10833 10K 1% 0,1W
3782 4822 117 10833 10K 1% 0,1W
3783 4822 051 20182 1K80 5% 0,1W
3784 4822 051 10102 1K00 2% 0,25W
3785 4822 051 10102 1K00 2% 0,25W
3788 4822 051 20104 100K00 5% 0,1W
4701 4822 051 20008 0R00 JUMP. (0805)
to
4720 4822 051 20008 0R00 JUMP. (0805)
5701 4822 242 72527 CST4,00MGW-TF01
7701 4822 209 17347 M62460FP
7780 4822 209 83357 NJM4560M
CAPACITORS
RESISTORS
ICs
FILTERS
JUMPERS
