Marantz SR3000 - Page 73

13-2
ELECTRICAL PARTSLIST - MONO BOARD
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
2642
4822 124 21913 1UF 20% 63V
2652
2655
4822 124 21913 1UF 20% 63V
2658
2659
4822 124 22652 2,2UF 20% 50V
2664
2665
4822 121 43526 47NF 5% 250V
2670
2671
5322 122 31866 6,8NF 10% X7R 63V
2676
2677
5322 122 32654 22NF 10% X7R 63V
2688
2689
5322 121 42465 68NF 5% 63V
2700
2805
4822 126 14585 100NF 10% X7R 0805 50V
2808
2809 5322 122 34098 10NF 10% X7R 63V
2810 4822 124 12245 220UF 20% 10V
2811 5322 122 34098 10NF 10% X7R 63V
2812 4822 124 80144 220UF 20% 25V
2813 4822 124 21913 1UF 20% 63V
2814 4822 126 13692 47PF 1% NP0 63V
2815 4822 126 14585 100NF 10% X7R 0805 50V
2816 5322 122 32654 22NF 10% X7R 63V
2817 4822 124 21913 1UF 20% 63V
2818 5322 122 32654 22NF 10% X7R 63V
2821 5322 122 32654 22NF 10% X7R 63V
2822 5322 122 32654 22NF 10% X7R 63V
2831 5322 122 32531 100PF 5% NP0 50V
2832 4822 126 14585 100NF 10% X7R 0805 50V
2833 5322 122 32654 22NF 10% X7R 63V
2834
5322 122 32531 100PF 5% NP0 50V
2837
2851 5322 122 32658 22PF 5% 50V
2852 5322 122 32658 22PF 5% 50V
2853 4822 124 81151 22UF 50V
2854 4822 124 81151 22UF 50V
2855 5322 122 32531 100PF 5% NP0 50V
2856 5322 122 32531 100PF 5% NP0 50V
2857 4822 126 14585 100NF 10% X7R 0805 50V
2858 4822 124 41751 47UF 20% 50V
2860 4822 124 41751 47UF 20% 50V
2861 5322 122 32654 22NF 10% X7R 63V
2862
5322 12232531 100PF 5% NP0 50V
2867
2868 4822 122 33575 220PF 5% NP0 63V CASE 0805
2869 4822 122 33575 220PF 5% NP0 63V CASE 0805
2871
4822 122 33177 10NF 20% X7R 50V
2873
2875 4822 122 33177 10NF 20% X7R 50V
2876 4822 122 33177 10NF 20% X7R 50V
2877
5322 121 42386 100NF 5% 63V
2882
2883
5322 126 10511 1NF 5% NP0 50V
2886
2887 4822 122 33127 2,2NF 10% X7R 63V
2888 4822 122 33127 2,2NF 10% X7R 63V
2901 4822 124 81151 22UF 50V
2902 4822 124 40248 10UF 20% 63V
2903 5322 122 32287 4,7PF 5% NP0 50V
2904 4822 126 13751 47NF 10% X7R 63V
2905 4822 124 22652 2,2UF 20% 50V
2906 5322 122 32268 470PF 10% 50V
2908 4822 126 13473 220NF 80-20% 50V
2909 5322 126 10223 4,7NF 10% X7R 63V
2910 4822 122 33575 220PF 5% NP0 63V CASE 0805
2911 5322 122 32654 22NF 10% X7R 63V
2912 4822 124 81151 22UF 50V
2913 4822 124 22652 2,2UF 20% 50V
2914 5322 122 32268 470PF 10% 50V
2916 4822 126 13473 220NF 80-20% 50V
2917 5322 126 10223 4,7NF 10% X7R 63V
2918 4822 122 33575 220PF 5% NP0 63V CASE 0805
2919 4822 124 81151 22UF 50V
2920 4822 126 13473 220NF 80-20% 50V
2921 4822 126 13473 220NF 80-20% 50V
2922 5322 122 32287 4,7PF 5% NP0 50V
2923 4822 124 81151 22UF 50V
2924 4822 124 40248 10UF 20% 63V
2925 4822 124 40181 220UF 20% 10V
2926 4822 126 14585 100NF 10% X7R 0805 50V
2928 4822 122 33177 10NF 20% X7R 50V
2930
5322 122 32531 100PF 5% NP0 50V
2933
2934 5322 126 10511 1NF 5% NP0 50V
2937 5322 126 10794 220PF 5% NP0 63V
RESISTORS
3251 3000 4822 051 20471 470R00 5% 0,1W
3251 4000 4822 051 10102 1K00 2% 0,25W
3252 4822 117 10837 100K 1% 0.1W
3253 4822 117 10837 100K 1% 0.1W
3254 4822 117 11342 0R33 5% 2W
3256 4822 117 10833 10K 1% 0,1W
3257 4822 117 11342 0R33 5% 2W
3258 4822 051 20184 180K00 5% 0,1W
3259 4822 117 10361 680R 1% 0,1W
3260 4822 117 10834 47K 1% 0,1W
3263 4822 117 10361 680R 1% 0,1W
3264 4822 117 10837 100K 1% 0.1W
3265 4000 4822 052 10479 47R00 5% 0,33W
3266 4822 051 20223 22K00 5% 0,1W
3267 3000 4822 051 20392 3K90 5% 0,1W
3267 4000 4822 117 11507 6K8 1% 0,1W
3268 4822 051 20332 3K30 5% 0,1W
3269 4822 051 20332 3K30 5% 0,1W
3270 4822 052 10479 47R00 5% 0,33W
3271 4822 052 10479 47R00 5% 0,33W
3272 4822 051 20393 39K00 5% 0,1W
3291 4822 052 10109 10R00 5% 0,33W
3292 4822 116 83933 15K 1% 0,1W
3293 4822 117 10833 10K 1% 0,1W
3294 4822 117 10833 10K 1% 0,1W
3295 4822 116 83933 15K 1% 0,1W
3301 4822 052 10479 47R00 5% 0,33W
3303 4000 4822 116 83961 6K8 5%
3304 4822 117 11148 56K 1% 0,1W
3305
4822 117 10834 47K 1% 0,1W
3307
3308 4822 117 11148 56K 1% 0,1W
3309 4822 050 24708 4R70 1% 0,6W
3310 4822 051 20182 1K80 5% 0,1W
3311 4822 050 24708 4R70 1% 0,6W
3314 4822 117 11148 56K 1% 0,1W
3315 4822 051 20182 1K80 5% 0,1W
3316 4822 050 24708 4R70 1% 0,6W
3319 4822 117 11148 56K 1% 0,1W
3320 4822 051 10102 1K00 2% 0,25W
3322 4822 117 11148 56K 1% 0,1W
3323 4822 051 20182 1K80 5% 0,1W
3324 4822 117 11148 56K 1% 0,1W
3325 4000 4822 116 83961 6K8 5%
3326 4822 051 20333 33K00 5% 0,1W
