Marantz SR3000 - Page 76

ELECTRICAL PARTSLIST - MONO BOARD
13-5
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
POS.
MODEL
VERS.
PART NO. DESCRIPTION
NO COLOR
3938 4822 117 11449 2K2 1% 0,1W
3939 4822 117 11449 2K2 1% 0,1W
3940 4822 117 11503 220R 1% 0.1W
3941 4822 117 11503 220R 1% 0.1W
3943 3000 4822 117 10833 10K 1% 0,1W
3943 4000 4822 051 20223 22K00 5% 0,1W
3944 4822 117 11503 220R 1% 0.1W
3945 4822 117 11503 220R 1% 0.1W
3946 4822 051 20471 470R00 5% 0,1W
3947 4822 051 20471 470R00 5% 0,1W
3948 4822 117 11503 220R 1% 0.1W
3949 4822 117 11503 220R 1% 0.1W
3950
4822 051 20101 100R00 5% 0,1W
3955
JUMPERS
4251 4822 051 20008 0R00 JUMP. (0805)
4252 4822 051 20008 0R00 JUMP. (0805)
4253 4000 4822 051 20008 0R00 JUMP. (0805)
4254
4822 051 20008 0R00 JUMP. (0805)
4258
4259 3000 4822 051 20008 0R00 JUMP. (0805)
4260 4822 051 20008 0R00 JUMP. (0805)
4283
4822 051 20008 0R00 JUMP. (0805)
4285
4287 4822 051 20008 0R00 JUMP. (0805)
4320 4822 051 20008 0R00 JUMP. (0805)
4501
4822 051 20008 0R00 JUMP. (0805)
4503
4504 4000 4822 051 20008 0R00 JUMP. (0805)
4506 4822 051 20008 0R00 JUMP. (0805)
4512 3000 4822 051 20008 0R00 JUMP. (0805)
4513
4822 051 20008 0R00 JUMP. (0805)
4524
4526 4822 051 20008 0R00 JUMP. (0805)
4528
4822 051 20008 0R00 JUMP. (0805)
4533
4537
4822 051 20008 0R00 JUMP. (0805)
4545
4548 4822 051 20008 0R00 JUMP. (0805)
4550
4822 051 20008 0R00 JUMP. (0805)
4553
4555
4822 051 20008 0R00 JUMP. (0805)
4560
4563 4822 051 20008 0R00 JUMP. (0805)
4564 4822 051 20008 0R00 JUMP. (0805)
4565 4000 4822 051 20008 0R00 JUMP. (0805)
4566 4000 4822 051 20008 0R00 JUMP. (0805)
4641 3000 4822 051 20008 0R00 JUMP. (0805)
4642 4000 4822 051 20008 0R00 JUMP. (0805)
4644 4000 4822 051 20008 0R00 JUMP. (0805)
4651 4822 051 20008 0R00 JUMP. (0805)
4652 4822 051 20008 0R00 JUMP. (0805)
4653 4000 4822 051 20008 0R00 JUMP. (0805)
4801
4822 051 20008 0R00 JUMP. (0805)
4805
4832 4822 051 20008 0R00 JUMP. (0805)
4833 4822 051 20008 0R00 JUMP. (0805)
4835 4822 051 20008 0R00 JUMP. (0805)
4901 3000 4822 051 20008 0R00 JUMP. (0805)
4902
4822 051 20008 0R00 JUMP. (0805)
4905
4911 4822 051 20008 0R00 JUMP. (0805)
4913 4000 4822 051 20008 0R00 JUMP. (0805)
4914
4822 051 20008 0R00 JUMP. (0805)
4918
FILTERS
5301 4000 4822 157 70599 COIL
5302 3000 4822 157 62255 COIL
5303 4000 4822 157 70599 COIL
5304 3000 4822 157 62255 COIL
5305 4000 4822 157 70599 COIL
5306 3000 4822 157 62255 COIL
5901 4822 157 62255 COIL
5902 4822 157 62255 COIL
DIODES
6252 4822 130 82079 D3SBA20
6253 4822 130 82078 D5SBA20
6257
4822 130 31878 1N4003G
6259
6260 4822 209 33575 L7812CP
6261
4822 130 31878 1N4003G
6263
6265 4822 209 31841 L7805CP
6267 4822 209 31841 L7805CP
6268 4822 130 31878 1N4003G
6270 4822 130 34278 BZX79-B6V8
6271 4822 130 30621 1N4148
6274 3000 4822 130 31878 1N4003G
6275 3000 4822 130 31878 1N4003G
6276 4822 130 34173 BZX79-B5V6
6279 4822 130 30621 1N4148
6280 3000 4822 130 34281 BZX79-B15
6280 4000 4822 130 61219 BZX79-B10
6281 3000 4822 130 34281 BZX79-B15
6281 4000 4822 130 34441 BZX79-B22
6289 4822 130 30621 1N4148
6290 4822 130 30621 1N4148
6301 4000 4822 130 34382 BZX79-B8V2
6302 4000 4822 130 34382 BZX79-B8V2
6303 4822 130 30621 1N4148
6304 5322 130 31504 BZX79-B3V3
6305 4822 130 30621 1N4148
6501 4822 130 30621 1N4148
6601 4822 130 30621 1N4148
6602 4822 130 30621 1N4148
6641
4822 130 30621 1N4148
6648
6649 4822 130 31878 1N4003G
6650 4822 130 61219 BZX79-B10
6801
4822 130 34278 BZX79-B6V8
6808
6809 4822 130 30621 1N4148
6831 4822 130 30621 1N4148
6832 4822 130 30621 1N4148
6901 4822 130 30621 1N4148
6902 4822 130 30621 1N4148
6903 5322 130 31504 BZX79-B3V3
6904 4822 130 30621 1N4148
TRANSISITORS
7253 4822 130 60511 BC847B
7255 4822 130 60373 BC856B
7256 4822 130 60511 BC847B
7257 4822 130 41246 BC327-25
7258 4822 130 41246 BC327-25
7259 4822 130 60511 BC847B
7260 3000 4822 130 60511 BC847B
7260 4000 5322 130 60159 BC846B
7261 4822 130 60373 BC856B
