Marantz SR5005 - Page 107

Ref.No. Part No. Part Name Remarks Q'ty New
29 nsp HEAT SINK MAIN 2120211788000S 1
30 nsp SHEET RATING CHASSIS 1210211269000S 1
32 nsp BRACKET H SINK 4010056906010S 5
33 nsp BRACKET SMPS 4010214886000S 1
34 nsp CUSHION FOOT 4050211175000S 4
35 00M46BW057210 FOOT FRONT 4007210321000S 4
36 nsp CHASSIS MAIN 3200213506200S 1 *
37 nsp SUPPORTER PCB 4070001601010S 3
38 nsp BRACKET SIDE 4010210686000S 1
39 nsp SUPPORTER P.C. 4070210192000S 2
z
40 963101009710S POWER TRANS MAIN U1B 8200960660660S 1
z
40 963101009720S POWER TRANS MAIN N1SG,N1B 8200960660670S 1
z
40 963101009730S POWER TRANS MAIN K1B 8200960660680S 1
72 nsp CHASSIS BACK U1B 3207213566000S 1 *
72 nsp CHASSIS BACK N1SG,N1B 3207213566100S 1 *
72 nsp CHASSIS BACK K1B 3207213566300S 1 *
73 nsp PLATE EARTH CHASSIS 4470212006000S 4
76 00M07BW257010 TOP COVER U1B,N1B, K1B 3007211796000S 1
76 943403002040M TOP COVER N1SG 3007211796100S 1
77 nsp TAPE ACETATE CLOTH 1220210059050S 1
81 nsp CUSHION SIDE 4050213095000S 2
82 nsp CUSHION SCREW 4050213025000S 4
83 nsp SHEET CABINET 1210210235000S 5
90 nsp SPACER CARD 4300210062000S 1
★
91 963606012390S CABLE FLAT CARD 1.0MM L=250mm N711402512480S 1 *
★
92 00D9630235204 TR 2SB1647Y J5011647Y0170S 7
★
93 963219003340S TR 2SC KTC3964 J502396400010S 7
★
94 00D9630235301 TR 2SD2560Y J5032560Y0170S 7
★
95 nsp CLAMP CABLE 4330040343010S 7
SCREWS
A nsp SCREW (+2S 3*10 B-TYPE ZNW/BH) B020030101B10S 26
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH) B020030103B11S 46
E nsp
SCREW
(2S 3*14 P(Φ6)+S-WASHER ZNY/HH)
B018230141H11S 21
F nsp SCREW (+2S 3*17 B-TYPE ZNW/BH) B020030171B10S 3
G nsp SCREW (+2S 4*8 B-TYPE(DOT) BK/BH) 1500040083B10S 2
H nsp
SCREW
(+3S 4*10 P+S-WASHER(ROUND)BK/BH)
B028940101B11S 4
I nsp SCREW (+2S 3*8 ZnY WASHER PI12) 1500001456010S 1
M nsp SCREW (+2S 3*8 B-TYPE ZNW/WPH) B020030081W10S 4
N nsp SCREW (+2S 2.6*6 B-TYPE ZNW/PH) B020026061P10S 1
P nsp SCREW (+2S 3*8 PI9.5 B-TYPE ZNW) 1500001206010S 2
Q nsp SCREW (+M 3*6 BK/BH) B000030063B10S 7
T nsp SCREW (+2S 3*8(ROUND) BK/BH) U1B,N1B, K1B B020230083B10S 51
T nsp SCREW (+2S 3*8(ROUND) BK/BH) N1SG B020230083B10S 45
U nsp SCREW (+2S 3*6 B-TYPE BK/BH ) B020030063B10S 1
V nsp SCREW (+2S 3*8 B-TYPE NI/BH) N1SG B020030084B10S 6
W nsp TOOTHED WASHER 1530210126000S 1
