Marantz SR5005 - PCB VIDEO ASSY

153
PCB VIDEO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U1001 00D9630116307 IC LC74781-9013-E J170747810010S
U1003 232810005504S IC BD7628F-E2 J127762800010S
U2003 235810046603S IC AVDM2000(NJW1327) J171132700010S
U2004 231310009508S IC PQ033DNA1ZPH J126033010010S
Q1001 00D9630120704 TR KRA102S(PB) N1B, N1SG, K1B J520010200210S
Q1002 00D9600296309 TR KRC111S (NM N1B, N1SG, K1B J522011100210S
Q1003 963219010750S TR 2SA KTA1504G J5201504G0210S
Q1004 00D2730459903 TR KTC2874B N1B, N1SG, K1B J502287400010S
Q1005,1006 00D9630328302 TR 2SC KTC3875G(ALG) J5223875G0210S
Q2001,2002 963219010750S TR 2SA KTA1504G J5201504G0210S
Q2005 00D9630121606 TR KRC107S (NH) J522107S00210S
Q2006 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2009,2010 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D1001,1002 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1003,1004 963209003510S D,ESD CDS3C05HDMI1 K067030500010S
D2001,2002 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2005,2006 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2009 00D9630328603 D,SCHOTTKY RB521S-30 K125521300010S
RESISTORS GROUP
R1030 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2001-2004 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2092 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2094 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2096 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2098 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2100,2101 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
R2107-2109 nsp R,CHIP THICK 75-D,1/16W C20007501M161S
CAPACITORS GROUP
C1001-1009 nsp C,CERAMIC 10UF-K/10V D011106572200S
C1010-1012 nsp R,THICK 0-J,1/10W C200000060201S
C1013,1014 00D9630311607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C1015 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1016 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1017 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C1018,1019 nsp C,CERAMIC 27PF-J/50V D010270167160S
C1020 nsp C,CERAMIC COG24PF-J/50V D010240167160S
C1021 nsp C,CERAMIC HIK X7R1200PF-K/50V D011122777160S
C1022 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1023 nsp C,CERAMIC COG24PF-J/50V D010240167160S
C1024 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1025 nsp C,ELECT 47UF-M/16V D040470083080S
C1026 00D9630311607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C1027,1028 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C1029,1030 nsp C,ELECT 47UF-M/16V D040470083080S
