2. RADIATOR ASSY
(1) Remove the screws.
(2) Remove the screws.
CABINET TOP
FRONT PANEL ASSY
→
RADIATOR ASSY
→
Proceeding :
View from bottom
Direction of photograph: D
Direction of photograph: C
STYLEPIN : Loose
cut
