(3) Disconnect the connector wires.
PCB 7CH AMP
PCB 7CH AMP
RADIATOR ASSY
CP401
CP405CP403CP402
N2706
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in RADIATOR ASSY.
