Marantz SR5005 - PCB HDMI ASSY

159
PCB HDMI ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U1001 nsp IC ADV7840 J040784005510S
U1301 00D2622557900 IC SN74LV14APWR J040741400180S
U1302 nsp IC ANALOG ABT1030 J080103005510S
U1303 963244012410S IC IS42S16400F-6TL J001421640060S
U1501 963239010410S IC ADV7511BSTZ-225 J040751100010S
U1703 00D2623077900 IC TC74VHCU04FT J040740405580S
U1706 236810062608S IC LC89058W-E J046890580020S
U1707 963243010640S
IC PAL/PLD
(EPM3032A-TC44)
8952161100040
U1901 nsp IC ADSP21367KSWZ2A1181 J080213675520S
U1902 246810048609S IC W9864G2IH-6 J001986460060S
U1903 963248012190M
IC MEMORY FLASH
(EN29LV160BB-70TI)
8952160100030
U2101 236810086505S IC AK5358BET-E2 J043535805520S
U2102 236810073509S IC AK4358VQ-L J042435800010S
U2103 00D2631289900 IC AZ4580M J121458000020S
U2104 00D2631289900 IC AZ4580M J121458000020S
U2105 00D2631289900 IC AZ4580M J121458000020S
U2106 00D2631289900 IC AZ4580M J121458000020S
U2301 963248012200M
IC MEMORY FLASH
(EN29LV160BT-70TIP)
8952160100040
U2302 963244012410S IS42S16400F-6TL J001421640060S
U2303 nsp IC MFI341S2164 J044341216410S
U2304 963239008830S IC TCC8600 32BIT J085860000010S
U2305 236810070500S IC AK4424ET-E2 TSSOP16 J042442405520S
U2306 00D2790055907 SW,POLY MICROSMD175F G300017500010S
U2501 nsp IC EX3AV J048030030010S
U2502 nsp IC EX3AV J048030030010S
U2503 nsp IC EX3AV J048030030010S
U2504 231310009508S IC PQ033DNA1ZPH J126033010010S
U2505 231310009508S IC PQ033DNA1ZPH J126033010010S
U2506 234810015507S IC BU4248F J126424800010S
U2901 00MHC007805KZ IC TC74VHCT125AFT J040741255580S
U2903 00D2623437906 IC TC74VHCT244AFT J040742445540S
U2904 00D2623410907 IC TC74VHCT08AFT U1B J040740800090S
U2905 00D2623444902 IC TC74VHC08FT U1B,N1B,N1SG J040740800280S
U3101 963262012150M MODULE REMOCON R94EV1A E940941003610S
U3102 963243012300M
IC CPU MICRO PROCESS
(R5F64169DFD )
8952500500010 *
U3103 246810026500S IC R1EX24256ASAS0A J000242565550S
U3301 963243012310M
IC CPU MICRO PROCESS
(R5F3650KNFB)
8952500500020 *
Q1001 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1002 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1003 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1004 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1005 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1006 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1007 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1008,1009 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1301 00D9600285006 TR KRC104S (ND) J522104S00210S
NOTE :
When update Firmware,
please confi rm a last
version in SDI.
Use the service board
after updating it.
