Marantz SR5005 - PARTS LIST OF EXPLODED VIEW

PARTS LIST OF EXPLODED VIEW
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
U : North America model N : Europe model K : China model
B : Black model SG : Silver gold model
Ref.No. Part No. Part Name Remarks Q'ty New
50 nsp PCB 7CH_AMP ASSY U1B 7025HK0929010 1
50 nsp PCB 7CH_AMP ASSY K1B 7025HK0929020 1
50 nsp PCB 7CH_AMP ASSY N1B,N1SG 7025HK0929040 1
51A nsp PCB SPK ASSY U1B 7025HK0929011 1
51A nsp PCB SPK ASSY N1B,N1SG 7025HK0929041 1
51 - PCB SPK -
52 - PCB SMPS -
54A nsp PCB REG_CNT ASSY U1B 7025HK0929012 1
51A nsp PCB SPK ASSY K1B 7025HK0929021 1
54A nsp PCB REG_CNT ASSY N1B,N1SG 7025HK0929042 1
53 - PCB REG - 1
54 - PCB REG_CNT - 1
55 - PCB FRONT_CNT - 1
56 - PCB SIDE_CNT - 1
57 - PCB RS232 - 1
58 - PCB SIRIUS - 1
26A nsp PCB FRONT ASSY U1B 7025HK0929013 1 *
26A nsp PCB FRONT ASSY K1B 7025HK0929023 1 *
26A nsp PCB FRONT ASSY N1B,N1SG 7025HK0929043 1 *
26 - PCB FRONT - 1
59-1 PCB USB - 1
59-2 - PCB MIC_H/P - 1
60 - PCB GUIDE_L - 1
61 - PCB H/S GUIDE - 1
62 - PCB GUIDE_R - 1
63 nsp PCB VIDEO ASSY U1B 7025HK0929014 1
63 nsp PCB VIDEO ASSY K1B 7025HK0929024 1
63 nsp PCB VIDEO ASSY N1B,N1SG 7025HK0929044 1
64A nsp PCB AUDIO ASSY U1B 7025HK0929015 1
64A nsp PCB AUDIO ASSY K1B 7025HK0929025 1
64A nsp PCB AUDIO ASSY N1B,N1SG 7025HK0929045 1
64 - PCB AUDIO - 1
65 - PCB PREOUT - 1
Ref.No. Part No. Part Name Remarks Q'ty New
66 8U6331006600M PCB HDMI ASSY U1B 7025HK0929018 1 *
66 - PCB HDMI ASSY K1B 7025HK0929028 1 *
66 - PCB HDMI ASSY N1B,N1SG 7025HK0929048 1 *
1 963402012060M PANEL FRONT U1B 3067214976000S 1 *
1 963402012040M PANEL FRONT N1B, K1B 3067214976010S 1 *
1 963402012050M PANEL FRONT N1SG 3067214976100S 1 *
2 963421006200M BADGE(MARANTZ) SILVER/GRAY 5630210678000S 1
3 963416012230M WINDOW DISPLAY 5077213053000S 1 *
4 943415004150M DOOR FRONT U1B,N1B, K1B 5047210656000S 1
4 943415004160M DOOR FRONT N1SG 5047210656100S 1
5 943454004170M DOOR MOLD U1B,N1B, K1B 5040210641000S 1
5 943454004180M DOOR MOLD N1SG 5047210641100S 1
6 412410005014M KNOB ASSY VOLUME U1B,N1B, K1B 5088212398000SZ 2
6 943412002020M KNOB ASSY VOLUME N1SG 5088212398010SZ 2
7 424510002017M DECORATION RING KNOB U1B,N1B, K1B 5127210971000S 2
7 943424002030M DECORATION RING KNOB N1SG 5127210971100S 2
8 nsp PLATE EARTH DOOR 4470211966000S 1
9 943402004240M PANEL SUB U1B,N1B, K1B 3067214941000S 1
9 943402004250M PANEL SUB N1SG 3067214941100S 1
10 nsp DAMPER GEAR 3660210043000S 1
11 nsp SHAFT BASE 2400210046000S 2
12 963422012240M SHEET FRONT U1B,N1B, K1B 1217211272000S 1 *
12 963422012250M SHEET FRONT N1SG 1217211272100S 1 *
13 963404012260M PANEL SIDE L U1B,N1B, K1B 3067214951000S 1 *
13 963404012270M PANEL SIDE L N1SG 3067214951100S 1 *
14 943422003540M PANEL SIDE R U1B,N1B, K1B 3067214961000S 1
14 943422003570M PANEL SIDE R N1SG 3067214961100S 1
15 00M10BW355010 LENS POWER 3710211083000S 1
16 963411006110M BUTTON POWER U1B,N1B, K1B 5090213961000S 1
16 963411012000M BUTTON POWER N1SG 5097213961100S 1
17 nsp MAGNET BASE 7600210059000S 1
18 943411004310M BUTTON-ASSY ENTER U1B,N1B, K1B 5098214491000S 1
18 943411004300M BUTTON-ASSY ENTER N1SG 5098214491100S 1
19 943411004290M BUTTON 10KEY U1B,N1B, K1B 5090214421000S 1
19 943411004280M BUTTON 10KEY N1SG 5097214421100S 1
20 00M10BW355020 LENS THX 3710211073000S 1
21 00M03CW355010 LENS HDMI 3710211063000S 1
22 nsp BRACKET BODY 4010214956000S 1
23 nsp SHEET V-AUX U1B,N1B, K1B 1217211332000S 1 *
23 nsp SHEET V-AUX N1SG 1217211332010S 1 *
24 nsp CUSHION DOOR 4050213145100S 2
25 nsp INLET TAPE 1220210759000S 1
27 nsp BRACKET BASE 4010214926000S 1
28 nsp WASHER 1530210142010S 1
106
NOTE :
Please change the parts when changing SR5005U1B (8U6331006600M) to other destination. (Please refer to the table below.)
Please refer to parts 99,100,101 page.
(SCHEMATIC DIAGRAMS : 24/28,25/28,26/28)
R2704
(
24/28
）
R2906
（
25/28
）
R2907
（
25/28
）
U2904
（
25/28
）
U2905
（
25/28
）
C2906
（
25/28
）
C2907
（
25/28
）
R2908
（
25/28
）
R2909
（
25/28
）
R2938
（
25/28
）
R3119
（
26/28
）
R3122
（
26/28
）
U1B 10K OPEN 33 TC74VHCT08AFT TC74VHC08FT 0.1/10 0.1/10 33 33 470K 10K OPEN
N1B 4.7K 33 OPEN OPEN TC74VHC08FT OPEN 0.1/10 33 33 470K OPEN 10K
N1SG 4.7K 33 OPEN OPEN TC74VHC08FT OPEN 0.1/10 33 33 470K OPEN 10K
K1B 4.7K OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN OPEN 10K 10K
