9. Console Side inputs
Figure 9: Side of Console Inputs
Port #4. (optional)
Port #3. (optional)
Port #2. Primer Orientation Sensor (optional)
Port #1. &
AC INPUT & Power ON/OFF Receptacle: Units are configured in either 110V or 220V.
6-Pin: Motor to Console DC Power Cord
Tablet Power Cord: Connect to tablet
WARNING
Never power on the console switch without the 6-pin molex connector plugged in and never install this
connector with the power already on since the DC voltage would damage the motor's input contacts.
