2. Mounting Evolution to Baseplate
Remove the Handle from the Evolution
TM
and place the Press on front of the Autodrive baseplate in the
orientation shown below. Using the 4X 3/8-24 by 1.75” Socket Cap Screws secure the press to the
baseplate. Be mindful not to drag the bottom of the press against the baseplate.
Figure 2 : Mounting to Baseplate
Mounting
Hardware (QTY 4)
Leave Shaft
Adapter Installed
