Mark 7 Evolution - Removal of Main Autodrive Assembly

MARK 7® RELOADING EVOLUTION USER MANUAL VERSION 1.1, COPYRIGHT 2018
ALL RIGHTS RESERVED
7
1. Removal of Main Autodrive assembly from the packing carton
Upon removal carefully inspect contents for damage. Damage that occurs during shipment should be
reported immediately to the carrier. Major system components listed below.
Figure 1: Major Component Overview
Electronics
Console
Base Plate
Rubber Feet
(4 Corners)
Drive
Sprocket
Motor Mount
Belt Tensioning
shoulder Bolt
Gear Box
Motor
