Martin Audio DX0.5 User Manual


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 14

…………
DX0.52x6LoudspeakerManagementsystemFeatures:Rear
Panel

1.Power
Usethisrocker‐styleswitchtoturntheunitonoroff.Theprocessorisonwhenthetopoftheswitchispressedin.Itisoffwhen
thebottomoftheswitchispressedin.TheLCDDisplay[6]willilluminateandtextwillappearwhenthepowerswitch
ison.
TheDX0.5 remembers itssettings, soyou may powercycle the unitandit will resume operationusingthesame settingsas
before.TheDX0.5employsrelaysontheoutputstoprevent unwantedpopsandnoiseinthesystemwhenpowercyclingand
startinguptheprocessor.After
engagingthepowerswitch,theunitwillinitializeandtherelayswillswitch.Anyliveoutputswill
smoothlyfadefromsilencetotheirconfiguredoutputlevels.Theprocessormaynowbeedited,oritisreadyforuseiftheDX0.5
isalreadyconfiguredfortheloudspeakersystemundercontrol.
2.PowerLeadSocketandFuse
Thisiswheretoconnectthedetachablepower cableincludedwiththeprocessor.Plugtheotherendofthepowerleadintoan
ACoutlet.Theoutletshouldmatchthepowercable.
WARNING:Bypassingtheplug’ssafetygroundpincanbedangerous.Don’tdoit!
Thefuseislocatedbehindthe
fusecover,atthebottomoftheIECsocket.Seethe“Troubleshooting”sectiononpage22for
informationaboutreplacingth e fuse.
3.Main:Lift/Gnd
Thegroundliftseparatesthechassisgroundfromthesignalground.ThedefaultpositionisGND.Youmayattempttoremedy
systemgroundloophumbymovingtheswitchtoLIFT.
4.XLROutputs
ThesesixmaleXLRconnectorsprovideabalancedline‐levelsignalforeachoftheprocessor’soutputchannels.Connecttheseto
theinputsofpoweramplifiersand/orpoweredloudspeakers.
5.XLRInputs
ThesefemaleXLRconnectorsacceptabalancedline‐levelinputfromamixerorothersourcemainL/Routput.
DX0.5 2x6 Loudspeaker Management system Features:
FrontPanel
6.LCDDisplay
TheLCDDisplayisoneofthemostvitalfeaturesoftheprocessor.Itdisplaysprocessorinformationincluding(butnotlimitedto)
System,PresetandSecurityUtilities,gain,delay,EQandotherinputandoutputprocessingparameters.
WhentheDX0.5ispoweredup,thelaststateitwasinwillload
upandtheLCDDisplaywillpresentthecurrentsystemsetup
type:
 2xStereo+Sub[default]
 2x2Way+Sub
 2x3Way
 3xStereo
 1x6Way

7.Nav/Edit1Control
