DX0.5 USERGUIDE
HAM09224UserGuideV1.0 22

…………
 ±0.0208msperclick,or
 ±0.007mperclick,or
 ±0.023feetperclick

TurningtheseControlsclockw ise increasesthedelaytime,whileturningthemanticlockwisedecreasesthedelaytime.
Theminimumandmaximumdelayrangesfrom:
 0.0000ms–600.9984ms
 0.000m–204.339
m
 0.000feet–670.233feet

PresstheESCbutton[11]todisengageEditing.
EQBypass
EQBypassflattensthe5‐BandEQontheinputsoyoumayhearexactlyhowitisaffectingthesystem.BytogglingtheEQBypass
onandoff,youmayquicklycomparethesoundwithandwithoutEQ.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenBypass = Off
[default]andBypass = On.
PresstheESCbutton[11]toacceptthenewEQBypassmodeandexittheEQBypasseditingmode.
5‐BandEQ
EditinginputEQontheDX0.5isusefulforadjustingtheresponseoftheentirePA,particularlywhencorrectinganomaliescaused
by venue acoustics. It is standard practice to use the input EQ for this function leaving the output EQ for any cabinet EQ
recommendedbythesystemmanufacturer.
Pressthe
Enterbutton[10]toenterandedittheEQbands.Anarrow–>willappearnexttoEQindicatingthatitisreadytobe
edited.
UsetheNav/Edit1[7]Controltochangethefrequencyby±1/24octave perclick.Turningthiscontrolclockwiseincreasesthe
frequency,whileturningit
anti‐clockwisedecreasesthefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
UsetheEdit2[8]ControltochangetheQfactor(bandwidth)by±0.05perclick.TurningthisControlclockwiseincreasestheQ
factor,whileturningitanticlockwisedecreasestheQ.TheEQbandmaybeconfiguredas
highorlowshelfbyturningitallthe
wayanti‐clockwise.
ThesearetheEQchoicesfromthefurthestanticlockwiseoptiontothefurthestclockwiseoption: 
 –12HighShelving
 –6HighShelving
 –12LowShelving
 –6LowShelving
 0.05–3.00[Parametric]

Tochange
theEQbetweenshelvingandparametric,thegainmustfirstbesetto0.0dB.
UsetheEdit3[9]Controltochangethegainby±0.5dBperclick.Turningthiscontrolclockwiseincreasesthegain,whileturning
itanti‐clockwisedecreasesthegain.Thegainrangesfrom–15.0dB
to+15.0dB.
PresstheESCbutton[11]toexittheEQeditingmode.
Outputs1‐6:
EngagingEditonOutput(s)1‐6allowsyoutoeditthefollowing:
 Name
 Source
 Polarity
 Gain
