DX0.5 USERGUIDE
HAM09224UserGuideV1.0 15

…………
TheNav/Edit1rotaryencodercontrolallowsyoutonavigatetheuserinterface,editsectionsoftheprocessor,navigatewithin
screenstoselectsub‐menus,pagesandparameters,aswellasselectvaluesduringediting.
8.Edit2Control
TheEdit2rotaryencodercontrolallowsyoutoeditparameters,aswellasselectvaluesduringediting.
9.Edit3Control
TheEdit3rotaryencodercontrolalsoallowsyoutoeditparameters,aswellasselectvaluesduringediting.
Ingeneral,usetheNav/Edit1rotaryencodercontroltoscrollthroughthevariouspagesandconfigurationsettings.Depending
onthepage,individualparametersmaybechangedbyturningone(ormore)ofthe
encoders.Insomecases,theEdit2andEdit3
controlsprovidefineandcoursecontrolofthesameparameter.
10.EnterButton
TheEnterButtonallowsyoutodigdeeperanddeeperintomenusandparameters,confirmoperationsandchangesettings.
11.ESCButton
TheESCButtonallowsyoutoretreatfromselectedvariables.Insomecases,itconfirmoperationsandchangessettings,aswell.
Thesewillbenoted.
12.UtilityButton
PressthisbuttontoselectandupdatetheDX0.5’sutilities.Therearethreemainutilitiesmenus:
 SystemUtilities
 PresetUtilities
 SecurityUtilities

Withineach,anarrayofsub‐menusareavailable.
13.Mute/EditButtons
Theseeightbuttonsserveadualpurpose:
 Mutingselectedinputsandoutputs
 Editingselectedinputsandoutputs

Tomuteaninputoroutput,quicklypressandreleasethedesiredbuttononcetoengage mute;quicklypressandreleaseitagain
toun‐mute.Muteasyoumightexpect
togglesbetweenmutedandunmutedonthecorrespondinginputsandoutputs.
Toeditaninputoroutput,pressandholdthedesiredbuttonuntil thatinputoroutput’sblueLED[14]illuminates.Pressand
holdagaintotakeitoutofeditmode.Editallowsyoutoedit–change–
variablesonthechoseninputsandoutputs.Whileitis
notpossibletoedittheinputsANDoutputssimultaneously,itispossibletolinkandedittheinputssimultaneouslyORlinkand
editanynumberofoutputssimultaneously.SimplypressandholdanyadditionalinputoroutputMute/Edit
buttonstolink.Any
changedparameterswillaffectalllinkedinputsoroutputs.
14.EditLEDs
ThereareatotalofeightEditLEDsontheDX0.5:twoinputandsixoutput.EditLEDsilluminatebluewhenengaged.SeeMute/
EditButtons[13].
15.MuteLEDs
ThereareatotalofeightMuteLEDsontheDX0.5:twoinputandsixoutput.MuteLEDsilluminateredwhenengaged.SeeMute
/EditButtons[13].
16.Meters
