DX0.5 USERGUIDE
HAM09224UserGuideV1.0 25

…………
 0.000m–204.339m
 0.000feet–670.233feet

PresstheESCbutton[11]toexitdelayeditingmode.
HighPassFilter
HighPassFiltersareutilizedtosetupcrossoversinmulti‐wayloudspeakerandsubwoofersystems.Theymayalsobeusedto
roll‐offlowfrequenciesthatfull‐rangeloudspeakerscannotefficientlyreproduce.
UsetheEdit2[8]Controltochangethefrequency.Turningthiscontrolclockwiseincreasesthefrequency,whileturning
itanti‐
clockwisedecreasesthefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
TurntheEdit3[9]Controltoseethevariousfiltertypeandslopeoptions:
 NoCut‐Off
 Butterworth6dB
 Butterworth12dB
 Linkwitz‐Riley12dB
 Bessel12dB
 Butterworth18dB
 Butterworth24dB
 Linkwitz‐Riley24dB
 Bessel24dB

PresstheESCbutton[11]toexitthiseditmode.
LowPassFilter
Inconjunctionwithhighpassfilters,lowpassfiltersareutilizedtosetupcrossoversinmulti‐wayloudspeakerandsubwoofer
systems.Forexample,ina3‐waystereosystem,usethehighandlowpassfiltersontheoutputfeedingthemid‐rangetransducer
todefinetherangeoffrequencies
itwillreproduce.Combinedwithhighandlowpassfiltersontheoutputstothelowandhigh
frequencytransducers,youmaydividethefrequency spectrumsoeachtransducerisreproducingtherangeforwhichitisbest
suited,makingthesystemsounditsbestandoperatemostefficiently.
Use
theEdit2[8]Controltochangethefrequency.Turningthiscontrolclockwiseincreasesthefrequency,whileturningitanti‐
clockwisedecreasesthefrequency.Thefrequencyrangesfrom20.0Hzto20.0kHz.
TurntheEdit3[9]Controltoseethevariousfiltertypeandslopeoptions:
 NoCut‐Off

Butterworth6dB
 Butterworth12dB
 Linkwitz‐Riley12dB
 Bessel12dB
 Butterworth18dB
 Butterworth24dB
 Linkwitz‐Riley24dB
 Bessel24dB

PresstheESCbutton[11]toexitthiseditmode.
Limiter
Eachoutputhasapowerfullimiterthatmaybeusedtoprotectloudspeakersfromdamageduetoexcessiveoutputlevelsfrom
themixer.Limiterparametersare publishedforallMartinAudiosystemsonourwebsiteandwhilstweacceptthatpersonal
preferencemay meanthatotherparametersmaybechangedfrom
ourpublishedfigures‐EQchangedforpersonalpreference
forexample‐we wouldstrongly recommendthat therecommendedlimiter parametersarealways usedtomaintain reliable
operationformanyyears.
ThreeLimitercontrolsmaybeedited:
